680 Synergy Plus – Digital Weight Indicator
7.6

Internet Setting Commands

Command
WIRED.MACID Ethernet hardware MAC ID (read only)
WIRED.DHCP Enable Ethernet DHCP
WIRED.ENABLED Enable wired Ethernet adapter
WIRED.IPADDR Ethernet IP address
WIRED.SUBNET Ethernet subnet mask
WIRED.GATEWAY Ethernet gateway
TCPC1.ECHO TCP Client 1 echo
TCPC1.EOLDLY TCP Client 1 end-of-line delay
TCPC1.IPADDR TCP Client 1 remote server IP
TCPC1.LINETERM TCP Client 1 line termination
TCPC1.NAME TCP Client 1 name
TCPC1.PORT TCP Client 1 remote server port
TCPC1.RESPONSE TCP Client 1 response
TCPC1.DISCTIME TCP Client 1 disconnect time (in seconds)
TCPC1.INPUT TCP Client 1 input function
TCPS.ECHO TCP Server echo
TCPS.INPUT TCP Server input type
TCPS.LINETERM TCP Server line termination
TCPS.NAME TCP Server name
TCPS.PORT TCP Server port number
TCPS.RESPONSE TCP Server response
USB.INPUT USB input function
USB.LINETERM USB line terminator
USB.ECHO USB echo
USB.RESPONSE USB response
USB.EOLDLY USB end of line delay
USB.PRINTMSG USB print message
* A valid IP consists of four numbers, in the range of 0 to 255, separated by a decimal point (127.0.0.1 and 192.165.0.230 are valid IP addresses)
7.7

Stream Setting Commands

Command
STRM.FORMAT#n Stream format
STRM.CUSTOM#n Custom stream definition
STRM.GROSS#n Mode token when streaming the Gross weight
STRM.NET#n Mode token when streaming the Net weight
STRM.PRI#n Units token when streaming Primary units
STRM.SEC#n Units token when streaming Secondary units
STRM.INVALID#n Status token when streaming an Invalid weight
STRM.MOTION#n Status token when the weight is in motion
STRM.POS#n Polarity token when the weight is positive
STRM.NEG#n Polarity token when the weight is negative
STRM.OK#n Status token when the weight is OK (not invalid, out
of range, at zero, or in motion)
STRM.TARE#n Mode token when streaming the tare weight
STRM.RANGE#n Status token when the weight is Out of Range
STRM.ZERO#n Status token when the weight is at Center of Zero
For commands ending with #n, n is the stream format number (1)
48 Visit our website
Description
Table 7-6. Ethernet TCP/IP and Wi-Fi Commands
Description
Table 7-7. Stream Formatting Commands
www.RiceLake.com
Values
xx:xx:xx:xx:xx:xx, 00:00:00:00:00:00 (default)
ON (default), OFF
ON, OFF (default)
Valid IP xxx.xxx.xxx.xxx*, 0.0.0.0 (default)
Valid IP xxx.xxx.xxx.xxx*, 255.255.255.0 (default)
Valid IP xxx.xxx.xxx.xxx*, 0.0.0.0 (default)
ON (default), OFF
0–255 (in 0.1 sec intervals), 0 (default)
Valid IP xxx.xxx.xxx.xxx*, 0.0.0.0 (default)
CR/LF (default), CR
Up to 16 alphanumeric characters, TCPC1 (default)
1025–65535, 10001 (default)
ON (default), OFF
0–60 (0= do not disconnect), 0 (default)
CMD (default), STRIND, STRLFT, REMOTE
ON (default), OFF
CMD (default)
CR/LF (default), CR
Up to 16 alphanumeric characters, TCPS (default)
1025–65535, 10001 (default)
ON (default), OFF
CMD (default), STRIND, STRLFT, REMOTE
CR/LF (default), CR
ON (default), OFF
ON (default), OFF
0–255, 0 (default)
ON (default), OFF
RLWS (default), CARDNAL, WTRONIX, TOLEDO, CUSTOM
Up to 1000 alphanumeric characters
Up to 8 alphanumeric characters, G (default)
Up to 8 alphanumeric characters, N (default)
Up to 8 alphanumeric characters, L (default)
Up to 8 alphanumeric characters, K (default)
Up to 2 alphanumeric characters, I (default)
Up to 2 alphanumeric characters, M (default)
SPACE (default), NONE, +
SPACE, NONE, – (default)
Up to 2 alphanumeric characters
Up to 8 alphanumeric characters, T (default)
Up to 2 alphanumeric characters, O (default)
Up to 2 alphanumeric characters, Z (default)
Values
