Item No. Part No.
1 190142 Enclosure, 680 Plus Indicator Multi-Segment LED Display
2 190230 Overlay, 680 Plus Indicator Membrane Switch with Numeric Keys
3 15650 Mount, Cable Tie 3/4''
15631 Cable Tie, 3'' Nylon
4 195684 680 Replacement CPU Board with Battery
194487 Screw, Metric M3 x 6 SEMS Phillips Pan Head with External Tooth Washer
5 71408 Battery, CR2032 3 V Lithium Manganese Dioxide
6 193108 Setup Switch Assembly, Remote
7 187876 Nut, Lock M5 Nylon Insert A2 SST
8 46381 #10 Bonded Sealing Washer, 18-8 SST
9 150800 Screw, Mach M5-0.8 x 10 Pan Phillips SST
10 180861 Screw, Mach M5 x 0.8 x 10 mm Slotted Drilled Cheese Head SST
11 15626 Cord Grip, PG9
30375 Seal Ring, PG9 Nylon
15627 Lock Nut, PG9
12 68600 Cord Grip, PG11
68599 Seal Ring, PG11 Nylon
68601 Lock Nut, PG11
13 19538 Post, Slotted Black Seal 1/4 x 1, Cord Grip - Post Only
14 103988 Washer, Nylon 0.515-0.52 ID x 1.00 x 0.093-0.094 Thick White Nylon 6/6
15 180825 Knob, M6 x 1 Threaded 32 mm Diameter 7-Lobe Nylon ZN-Plated Steel
16 29635 Tilt Stand, SST
17 180842 Power Cord Assembly, NEMA 5-15
180850 Power Cord Assembly, Europe CEE7/7
18 88733 Vent, Breather Sealed Gortex Membrane Black
19 88734 Nut, Breather Vent M12 x 1 Thread
20 193230 Screw, Mach M4 x 0.7 x 10 Phillips Pan Head SST
21 75062 #8 Bonded Sealing Washer, 7/16 OD SST
22 192562 Backplate, 680 Universal with Gore Vent Hole, No Options
23 84388 Gasket, Backplate
24 180826 Nut, KEP M4 x 0.7 External Tooth Lock Washer 18-8 SST
25 194488 Screw, Mach SEMS M4 x 0.7 x 6 Phillips Pan Head External Tooth Lock Washer
26 15601 Wire, Ground 6'' with No. 8 Eye Connector
27 180856 Washer, M4 Internal Tooth SST
28 193281 Power supply, 12 V 15 W MeanWell RS-15-12
29 193337 Cable Assembly, 680 Power Harness, 2 Position, Flying Lead
30 192439 Bracket, power supply MeanWell 15 and 25 Watt
31 194487 Screw, Metric M3 x 6 SEMS Phillips Pan Head with External Tooth Washer
– 194477 680 Indicator Parts Kit
Description
NOTE: For Unit PN 193152 (AC - US) only
NOTE: For Unit PN 193153 (AC - EURO) only
NOTE: For AC units only
Table 2-11. Replacement Parts
© Rice Lake Weighing Systems ● All Rights Reserved
Installation
Qty
1
1
4
4
1
4
1
1
1
2
1
1
2
2
2
3
3
3
3
2
2
1
1
1
1
1
4
4
1
1
1
2
1
4
1
1
1
5
1
13
