Features - HITEC X4 AC Pro Instruction Manual

Features

Four Channel Charger:
The X4 AC Pro allows you to connect up to 4 batteries of varying chemistries
(NiMH/NiCd/LiPo/LiFe/Lilon/LiHV/Pb) to any of the charging channels. Each
channel can perform a process independently of each other.
Dual Input and Power Distribution:
The X4 AC Pro has a dual AC/DC input comprised of AC 100-240V and DC 11-
18V. In DC mode, the power of each channel A&B is 100W each with an overall
power of 200W, Channel C&D is 50W each with an overall power of 100W (total
charger power is 300W). Power distribution is supported in AC mode. For ex-
ample, if Channel A is 70W and Channel B is 30W, total power is 100W.
Optimized Operating Software:
The X4 AC Pro features an AUTO function that sets the feeding current during
charging or discharging. It can also disconnect the circuit automatically
and sound an alarm if an abnormal reaction has been detected. Each
programming feature of your X4 AC Pro is controlled by a two way linkage and
communication and is completely customizable to the user's preferences.
Battery Memory (Data Store/Load):
The charger can store up to 10 unique charge/discharge profiles for each
channel and lets you recall the data from each program setting at any time.
PC Control Software "Charge Master":
Equipped with free "Charge Master" software, the v AC Pro gives you the
unparalleled ability to operate the charger via your personal computer. You
can monitor pack voltage, cell voltage, and other data during battery charging
or view the charge data in real-time graphs. The "Charge Master" gives you the
option to initiate and update firmware as well.
Smart Phone Control via Wi-Fi Module (iOS and Android):
Finally, a battery charger with its own apps! This charger has built-in Bluetooth
4.0 and can be operated using a smart phone.
Internal Independent Lithium Battery Balancer
The X4 AC Pro features a built-in cell voltage balancer so you don't need to fuss
with external balancers while charging or discharging.
10
