VGA Wafer Connector (CN12)

This is a 2x5-pin (pitch=2.00mm) wafer connector for VGA interface.
Pin Signal
1 G_VGA_R
3 G_VGA_G
5 G_VGA_B
7 G_HSYNC
9 VGA_SCL
2.4.12

Front Audio Connector (CN14)

This is a 2x5-pin (pitch=2.00mm) connector for convenient connection and control of
audio devices.
Pin Signal
1 MIC_IN
3 LINE_IN_L
5 LINE_IN_R
7 AUD_OUT_L
9 AUD_OUT_R
16
Pin Signal
2 VGA_VCC
4 GND
6 GND
8 G_VSYNC
10 VGA_SDA
Pin Signal
2 GND
4 GND
6 GND
8 GND
10 GND
