ICO300-83B User's Manual
1.2.15

System LED

 There are showed the LED's indicators and functional descriptions.
LED Name
Indicate the storge status and it's flashing when storge
ACT
access.
Indicate the Power status. When the DC input is acceptable,
PWR
the LED will ON.
1.2.16 Operation Temperature
 -20℃ ~ +70℃
 -40℃ ~ +70℃ (optional for ICO300-83B-WT)
1.2.17 Storage Temperature
 -40℃ ~ +85℃
1.2.18 Humidity
 10% ~ 95% (non-condensation)
1.2.19 Weight
 1 kg
1.2.20 Dimensions

48mm(1.88") (W) x110mm(4.33") (D) x155mm(6.1") (H)
1.2.21 System I/O Outlets

Four 9-pin D-Sub male connectors, COM1~COM4.
 One 15-pin D-Sub female connector for VGA.
 Two 10/100/1000 Base-T RJ-45 with 1.5KV magnetic isolated protection.
 Four USB 3.0 connectors.
 One DC Power Input with terminal block.
 One 9-pin D-Sub Female connectors for DIO. (ICO300-83B-DIO)
 Three Antenna holes.
6
Description Color
Green
Yellow
Introduction
