The internal tank valves are located under the front access panel of the Nanodispenser
RS1000. Table 4.1 shows the valve operating positions that are used in some
maintenance procedures.
Table 4.1 Nanodispenser RS1000 Valve Operating Positions
Description
Position B–1
Normal operating position
using internal tanks.
Position A–2
Position for filling the internal
supply tank.
Position A–1
Normal operating position
using external tanks.
