6. Close the front access panel and the main door.
7. Tap OK in the on-screen instructions
The water from the internal supply tank is pumped through the wash system and
empties into the internal waste tank which, in turn, empties into the external waste
tank.
Figure C.16 Draining the Supply Tank
Fill the internal supply tank half-full:
1. Manually fill the internal supply tank to half capacity (see
2. Manually prime the water supply system (see
3. Reattach the tank access panel.
Return the supply valves to the external supply setting:
1. Open the main door and lift the front access panel to access the tank control valves.
2. Set the supply valves to position "A1" (see
3. Close the front access panel and the main door.
4. Tap the HOME button
5. Fill the external supply tank with Type 1, > 18.2
6. Reinsert the supply tubing into the external supply tank.
Make sure that the end of the tubing with the metal fitting is at the bottom of the tank
so that air will not be drawn into the tubing. The metal fitting helps compensate for
the tendency of the tubing to float when it is empty.
MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
(Figure C.16).
This message disappears when draining is done.
page 139
Table 4.1, page
in the "safety interlock is disengaged" on-screen message.
water.
MΩ
Appendix C External Tanks
page 99 for instructions).
for instructions).
89).
