Figure 1.10 Opening the Front Access Panel
To close the front access panel:
1. Grasp the sides of the front access panel.
There are two brackets, one under each side of the panel that hold it open.
Simultaneously lift up on the access panel lightly and press the brackets up to
disengage them from the locked position.
2. Lower the access panel closed.
!
CAUTION
Be careful not to pinch fingers underneath the panel as you close it against the body of the
instrument. Do not place hands in the main door pathway when closing it.
3. Press the access panel toward the body of the instrument until it snaps shut.
!
CAUTION
Do not push on the access panel when closing; release brackets and close carefully.
MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
Chapter 1 Introduction
Front access panel
