Chapter 1 Introduction
6
Figure 1.3 Instrument Back: Power Switch and Ports
For more information about these ports, see External ports, page 12.
Power Switch
Figure 1.2 Instrument Front
Touchscreen
Controls the
instrument
MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
Stop Button
Immediately stops
motion
I/O Port: Future expansion
USB 2.0 Ports (2): Data transfer,
keyboard, or mouse
VGA Port: External display
Ethernet Port: Sample tracking, data
transfer
