Chapter 1 Introduction
12

External ports

Instrument
specifications
The Nanodispenser RS1000 can be connected to an external:
• Keyboard with a USB connector
• Pointing device (for example, mouse or trackball with a USB connector)
• Monitor with a VGA connector
Figure 1.3, page 6 shows the port locations.
The keyboard and pointing device can be used to control the instrument instead of the
touch screen. A monitor connected to the VGA port acts as a "clone" display which
shows an image identical to that on the instrument touch screen.
The Ethernet port should be used to connect the instrument to a network solely for
transmitting sample-tracking and processing data, and for remote servicing by
Agena Bioscience Customer Support. The Ethernet port should not be used for
general networking. The I/O port is not currently used. It is reserved for future expansion.
Table 1.4 Nanodispenser RS1000 Dimensions and Weight
Item Specification
Width 28.4 inches (72.0 cm)
Height 25.9 inches (65.8 cm)
Depth 27.5 inches (69.8 cm)
Weight 155 pounds (70.3 kg)
Table 1.5 Nanodispenser RS1000 Power Supply and Consumption Characteristics
Item Description
Site power 100-240 VAC 50-60 Hz, 15A, properly grounded
Fuse T4AL 250V, 5x20 mm
Voltage detection Instrument automatically detects and selects proper
voltage within above range
Power consumption 3.2A maximum
Table 1.6 Acceptable Operating Environmental Conditions
Item Description
Temperature 61-75 °F (16-24 °C)
Humidity 30-75% relative humidity
Table 1.7 Physical Clearance Requirements
Area Next to
Description
Instrument
Above 16 inches (40.6 cm) to allow the main door to open fully.
Left 12 inches (30.5 cm) to allow access to supply and waste ports.
Right 12 inches (30.5 cm) to allow access to the power switch and cable on the
back of the instrument.
Rear 6 inches (15.2 cm) to allow access to power switch and space for power
cable and ventilation.
MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
USG-CUS-059 Rev05
