Description of Changes Deck Plate
Deck plate modified to
accept plate flatteners
instead of microtiter
plate (MTP) clips and
spacer blocks to enable
384-96 compatibility.
Overview of instrument
components
The Nanodispenser RS1000 has a factory-installed pin array format that can be adapted
to a different dispensing format using an optional adapter kit
Table 1.3 Pin Arrays
Instrument Pin
Available Adapter Kit
Format
24-pin Set 1 Pin Adapter Kit
(part no. 11329)
Note: This adapter kit
is not compatible with
the 38496 system
pin heads.
6-pin Set 1 Pin Adapter Kit
(part no. 10255)
Note: This adapter kit
is not compatible with
certain 6-pin heads.
24-pin Set 1 and 6 Pin Adapter Kit
(38496 (included with
compatible) instrument)
(part no. 10254)
Note: This adapter kit
is not compatible with
older 24-pin heads.
Figure 1.2 through Figure 1.7
MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
Left Side Panel
Type of Dispensing
Automatic dispensing from a 384-well microtiter plate
to a 384 SpectroCHIP Array.
Manual dispensing from a single well of a 384-well
microtiter plate to a single pad on a 384 SpectroCHIP
Array (using the 1 Pin Adapter Kit).
Automatic dispensing from a 96-well microtiter plate
to a 96 SpectroCHIP Array.
Manual dispensing from a single well of a 384-well
microtiter plate to a single pad on a 384 SpectroCHIP
Array (using the 1 Pin Adapter Kit).
Automatic dispensing from a 384-well microtiter plate
to a 384 SpectroCHIP Array.
Automatic dispensing from a 96-well microtiter plate
to a 96 SpectroCHIP Array (using the 6 Pin Adapter
Kit).
Manual dispensing from a single well of a 384-well
microtiter plate to a single pad on a 384 SpectroCHIP
Array (using the 1 Pin Adapter Kit).
show the main components of the Nanodispenser RS1000.
Chapter 1 Introduction
Front Panel
(Table 1.3).
