RGB Output port (FOXBOX Rx VGA only) (see
J
Connect an analog VGA-UXGA RGB or YUV video display to this 15-pin HD female
connector.
NOTE: If the transmitter input is RGB video, you can set the receiver to output the
desired video format: RGBHV or RGsB video.
If the input to a FOXBOX Tx VGA/YUV is component video, the output of the
receiver is YUV video only. Neither unit can convert the video into the RGB format.
DVI-I Output port (FOXBOX DVI only) (see
K
to this DVI-I connector (see
assignments).
NOTE: The FOXBOX DVI outputs only the digital signals on the DVI-I Output
connector. The analog pins on the port are not connected.
Audio port (see figure
L
(see figure 3 on page 8 for wiring).
RS-232 Over Fiber port (see
M
serial command signals to the receiver, for serial control of a projector for
example, connect the host device to the transmitter via the three leftmost
poles (Tx, Rx, and _) of this 5-pole captive screw connector (see
Over Fiber connections
NOTES:
• If you connect only one fiber optic cable (item
the receiver for daisy-chaining, you will not receive reports from the controlled
device. To receive responses from the controlled device, you must install two
fiber optic cables and leave the FOXBOX receiver in normal configuration (Mode
DIP switch 1 down).
•
The FOXBOX can pass RS-232 commands and responses at rates up to
115200 baud.
Alarm outputs port (see
N
of fiber optic link 1, connect a locally-constructed or furnished monitoring
device to the receiver via the two rightmost poles (1 and 2) of this 5-pole
captive screw connector. When the receiver does not detect a light link on
fiber cable Rx, pin 1 and pin 2 of this port are shorted together.
Optical port and LEDs (see
O
WARNING: The FOXBOX Tx/Rx outputs continuous invisible light (Class 1 rated),
which may be harmful to the eyes; use with caution. Plug the supplied dust cap
into the optical transceiver when the fiber optic cable is unplugged.
AVERTISSEMENT :
(conforme à la classe 1) qui peut être dangereux pour les yeux, à utiliser avec
précaution Branchez la protection contre la poussière dans l'ensemble émetteur/
récepteur lorsque le câble fibre optique est débranché.
figure 4
figure
DVI connector (FOXBOX DVI)
4) — Plug an audio device into this stereo mini jack connector
figure 4) — If you want the FOXBOX to pass
on page 16 to wire this connector).
figure 4) — For remote monitoring of the status
figure 4) —
Le FOXBOX Tx/Rx émet une lumière invisible en continu
FOXBOX Tx / Rx • Installation and Operation
on the previous page) —
4) — Connect a DVI video display
on page 15 for pin
RS-232
OVER FIBER
Tx Rx
RS-232
, below), or you configure
O
RS-232
OVER FIBER
Tx Rx
ALARM
1 2
ALARM
1 2
12
