Optical port and LEDs (see
F
WARNING: The FOXBOX Tx/Rx outputs continuous invisible light (Class 1 rated),
which may be harmful to the eyes; use with caution. Plug the supplied dust cap
into the optical transceiver when the fiber optic cable is unplugged.
AVERTISSEMENT :
(conforme à la classe 1) qui peut être dangereux pour les yeux, à utiliser avec
précaution Branchez la protection contre la poussière dans l'ensemble émetteur/
récepteur lorsque le câble fibre optique est débranché.
NOTES:
•
Ensure that you use the proper fiber cable for your transmitter/receiver pair.
Typically, singlemode fiber has a yellow jacket and multimode cable has an
orange or aqua jacket.
• Only one fiber optic cable, transmitter Tx to receiver Rx, is required for video,
audio, and serial command transmission. But, if you connect only one fiber
optic cable, or if your transmitter is configured to daisy-chain the optical signal,
system functionality is reduced. You will not receive RS-232 reports from the
controlled device, and some FOX Extenders Control Program functions and
RS-232 commands will not work. To receive responses from the controlled
device and for full functionality, you need to install both fiber optic cables and
leave the FOXBOX receiver in normal configuration (Mode DIP switch 1 down
on the receiver).
Tx (required) — For all one-way video, audio, and serial
1
communications from the transmitter to the receiver, connect a
fiber optic cable to the Tx LC connector.
Connect the free end of this fiber optic cable to the Rx connector
on the FOXBOX Rx receiver
compatible Extron FOX device.
Rx (optional) — Connect a fiber optic cable for all one-way return
2
serial communications from the receiver to the transmitter.
Connect the free end of this fiber optic cable to the Tx connector
on a FOXBOX Rx receiver in normal configuration
figure 12) or to any other compatible Extron FOX device.
Tx Link and Rx Link LEDs — When lit, the link is active (light is
received).
Configuration port (see
G
to this port via a 2.5 mm mini jack TRS RS-232 cable for RS-232 protocol control of
all FOXBOX functions. See
details on the adapter cable and
software control.
The TRS RS-232 cable is included with the Tx models.
DC power connector (see
H
supply into this connector (see
connector.
figure 2 on page 8) —
Le FOXBOX Tx/Rx émet une lumière invisible en continu
(item on figure 12) or to any other
O
figure 2) — Connect a controlling device, such as a PC,
Front panel Configuration ports
Remote Control on page 20 for SIS commands and
figure 2) — Plug the included external 12 VDC power
Power supply wiring
FOXBOX Tx / Rx • Installation and Operation
1 1
Transmitter
to
Receiver
(item on
O
on page 17 for more
on page 18, to wire the
Tx Rx
2 2
OPTICAL
Tx Rx
OPTICAL
