ECLYPSE Web Interface
Item Description
Click to refresh the information in the list.
Click to eject the USB key. This is highly recommended in order to avoid data corruption.
Select the checkbox next to the file or files you wish to delete.
Checkbox
Select the main selection checkbox at the top left corner of the list to select all or deselect all items in the list.
Target
Click to display a preview of the backup file information (name, status, model, firmware version, selected features, etc.). Directly
from this preview window, you can choose to restore the file.
Click to download the backup file (.ecybackup file) on your PC.
Filename Name of the backup file.
Restore Restore the selected backup file that is currently on your PC
Create Backup Start the backup. See
Import and Restore
Import on device and then restore the backup
Backup
Creating a Backup
The backup functionality guides you through a series of well-defined steps to easily create the data backup.
1. In the Backup & Restore main screen, click Create Backup. The options to create a new backup are displayed.
Figure 74: Creating a New Backup
2. In the Backup File Name section, enter the backup file name, and click Next.
nLight ECLYPSE
- Indicates that the backup is in the ECLYPSE controller
- Indicates that the backup is in the USB key
Creating a Backup.
