Figure 49: Radius Server Settings
To setup the RADIUS server settings, complete the parameters as described in the following table:
Item Description
Authentication Port RADIUS server authentication port number
Accounting Port RADIUS server accounting port number
Encryption key that devices use to encrypt and decrypt user authentication credentials that are sent between devices. The
shared key should be a long string made up of 16 to 132 random alphanumeric characters and symbols that would be
Shared Key
difficult to guess.
This same key must be copied to any RADIUS client.
Click to copy the shared key to the clipboard.
Click to refresh the information in the list.
Apply Click Apply to apply and save the changes

RADIUS Client Settings

When Radius Server is selected in the Client Settings tab the following configuration parameters shown in the table below
are available. This centralizes access management on the RADIUS server thereby saving time by eliminating the need to
add users to each controller individually. The client RADIUS server can be another ECLYPSE controller or a Microsoft
Windows Domain Active Directory Server. See
nLight ECLYPSE
Supported RADIUS Server Architectures.
ECLYPSE Web Interface
57
