Acuity Controls nLight ECLYPSE User Manual page 54

ECLYPSE Web Interface
4. Select the access levels the user will be able to use. Set one or more options according to the user's role:
ECLYPSE Roles
Admin
Operator
Viewer
Rest
Table 3: ECLYPSE Roles
BLE Room Device Roles are not available on the nLight ECLYPSE and can be ignored.
5. Click Next. The Welcome Page screen is displayed allowing you to define the user's landing page that will be dis-
played when they login to the controller.
Figure 45: User Details - Welcome Page
6. Enter the URL of the web page you want to define as the landing page. The URL is the one found after the controllers'
IP address or hostname. This should be copied from your Web browser's address bar when you have navigated to the
target page.
For example if the address for the user default web page is HOSTNAME/eclypse/envysion/index.html OR
192.168.0.10/#/bacnet.html, remove the hostname or IP Address so that the URL becomes /eclypse/envysion/in-
dex.html, or /#/bacnet.
7. Click OK, and because authentication is required, enter your username and password.
The edit icon
appears empty. You can leave the password as is or assign a new one.
nLight ECLYPSE
Description
Allows user access to the ENVYSION studio and viewer. The user can also view and modify all configuration
interface parameters. When this option is chosen, the user also receives Admin access for BLE Room Device Roles.
Allows user access to the ENVYSION interface in viewing mode as well as gives partial access to the ECLYPSE
Web Configuration Interface. Certain configuration interface screens are unavailable such as User Management,
Viewer Information, etc.
Allows user access to the ENVYSION interface in Viewing mode. The user is not allowed to access the ECLYPSE
Web Configuration Interface.
Allows a user to program the controller with a RESTful API enabled programming tool. This user does not have
access to the ECLYPSE Web Configuration Interface or ENVYSION.
is used to edit a user's information. When editing user information, the user password is not shown therefore the field
54
