Actual Speed Source; Actual Value Comparison - BONFIGLIOLI Vectron ACTIVE Manual

5.6.2
If speed sensor 2 of the expansion module is to deliver the actual value signal for the
speed controller, speed sensor 2 must be selected as the source. Switch-over is ef-
fected via parameter
the actual speed source.
5.6.3
The expansion module provides additional operation modes for parameters
Mode Comparator 1
in the operating instructions. These operation modes enable the comparison of the
speed of speed sensor 2 and the analog input EM-S1INA to the maximum speed and
the maximum analog input value, respectively.
108 and 116
06/05
06/05

Actual speed source

Actual Speed Source
Operation mode
1 -Speed sensor 1
2 -Speed sensor 2

Actual value comparison

540 and
Operation mode
8 -Abs. Actual speed 2
Analog input
16 -
EM-S1INA abs. Value
766. By default, speed sensor 1 is used as
The actual speed source is speed sensor 1 of the
basic device (factory setting).
The actual speed source is speed sensor 2 of the EM-
IO-03 expansion module.
Operation Mode Comparator 2
Speed Sensor 2 Speed
Maximum Frequency
culated from
Pole Pairs
373)
Analog input EM-S1INA
Operation modes with signs (+/-)
Function
Operation
543 which are described
Function
220 > maximum speed (cal-
No. of
419 and
253 > analog input 100%
