Electrical Installation; Circuit Diagram - BONFIGLIOLI Vectron ACTIVE Manual

3.3
Danger!
•
•
Danger!
3.3.1
Analog signal, I
Digital signal, response time approx. 16 ms, U
patible, frequency signal, 0...30 V, 10 mA at 24 V, f
Make contact, response time approx. 40 ms, 24 V AC / 1 A , 24 V DC / 1 A (ohmic)
Rated response resistance 2.85 kΩ (PTC) according to DIN 44081,
PTC or bimetal temperature sensor (break contact)
Analog signal, resolution 12 Bit, U
Analog signal, U
CAN actuation of the system bus according to ISO-DIS 11898 (CAN High Speed)
10
10

Electrical installation

If the following instructions are not complied with, there is direct danger
with the possible consequences of death or severe injury by electrical
current. Further, failure to comply can lead to destruction of the fre-
quency inverter and/or of the expansion module.
Before electrical installation of the EM-IO-03 expansion module, the frequency
inverter must be de-energized. Take appropriate measures to make sure it is not
energized unintentionally.
Make sure that the frequency inverter is de-energized.
The mains, direct voltage and motor sockets can have dangerous voltages
even after disconnection of the frequency inverter. Work may only be
done on the device after a waiting period of some minutes until the DC
link capacitors have been discharged.

Circuit diagram

A Analog current output EM-S2OUTA
= 0(4)...20 mA, U
out
B Digital inputs EM-S2IND ... EM-S3IND
C
Relay connection EM-S1OUTD
D Motor PTC Resistor Connection EM-MPTC
E Analog input EM-S1INA
F Analog voltage output EM- S1OUTA
= ±10 V, I
max
G Communication interface system bus
X410A
1
+20 V / 180 mA
2 GND 20 V
A
EM-S2OUTA
A 3
D
EM-S2IND
4
B
EM-S3IND
5
EM-S1OUTD
6
C
7
X410B
EM-MPTC
1
D
2
EM-S1INA A
E 3
D
EM-S1OUTA A
F 4
D
CAN-Low
5
SYS
CAN-High
G
6
7
GND
= 10 V, overload and short-circuit proof
max
= 30 V, 10 mA at 24 V, PLC com-
max
= ±10 V (Ri= 100 kΩ), I
max
= 2 mA, overload and short-circuit proof
max
= 150 kHz
max
= ±20 mA (Ri= 250 Ω)
max
