The digital output of the EM-IO-03 expansion module is designed as a relay make
contact. Parameterization of this digital output permits a linking to a variety of func-
tions. The selection of functions depends on the parameterized configuration.
5.4.2
The operation mode of the digital output (Terminals X410A.6 and 7) is selected via
the parameter
The selectable operation modes correspond to the table shown in the operating in-
structions of the frequency inverter in the chapter "Digital outputs".
5.5
The EM-IO-03 expansion module has two digital inputs. The assignment of the control
signals to the available software functions can be adapted to the application in ques-
tion. As a function of the selected
the selection of the operation mode differ. In addition to the digital control inputs
available, further internal logistic signals are also available as sources.
The individual software functions are assigned to the various signal sources via
parameterization-capable inputs. This enables a flexible and varied use of the digital
control signals.
Alongside the operation modes listed, those stated in the operating instructions of the
frequency inverter in the chapter "Digital inputs" also apply.
5.5.1
As a function of the
be used as reference values. The EM-IO-03 expansion module extends the functional-
ity described in the operating instructions of the frequency inverter (parameter
frequency change-over 1
ter
5
Fixed frequency
Fixed frequency
Fixed frequency
Fixed frequency
Fixed frequency
Fixed frequency
Fixed frequency
Fixed frequency
