Digital Inputs For Speed Sensor 2; Division Marks Speed Sensor 2 - BONFIGLIOLI Vectron ACTIVE Manual

5.6
The digital inputs EM-S2IND and EM-S3IND of the EM-IO-03 expansion module can be
set via the parameter
sponding operation mode for the evaluation of a unipolar 24V two-channel speed sen-
sor (incremental speed sensor).
Assignment of the inputs:
−
−
With the help of parameter
tion modes are available:
5.6.1
The number of increments of the connected speed sensor can be adjusted via the
parameter
speed sensor is to be selected according to the speed range of the application.
The maximum number of division marks S
150 kHz of the digital inputs EM-S2IND (track A) and EM-S3IND (track B).
To ensure a good true running of the drive mechanism, a sensor signal must be
evaluated at least every 2 ms (signal frequency f = 500 Hz). The minimum number of
division marks S
can be calculated from this requirement. The evaluation of four signal edges per mark
is firmly defined in the function of speed sensor 2.
64
64

Digital inputs for speed sensor 2

Operation mode Speed sensor 2
Digital input EM-S2IND: track A
Digital input EM-S3IND: track B
Operation mode
0 -Off
4 -Quadruple evaluation
Quadruple evaluation
104 -
inverted

Division marks speed sensor 2

Division marks speed sensor 2
S = 150 000 Hz ⋅
max
of the incremental speed sensor for a required minimum speed n
min
60
S = 500 Hz ⋅
min
A
Parameter
No. Description
494 Division marks speed sensor 2
Operation mode Speed sensor 2
Speed measurement not active The digital inputs are
available for further functions.
Two-channel speed sensor with recognition of direction
of rotation via track signals A and B;
four signal edges are evaluated per division mark.
Like operation mode 4; the actual speed value is in-
verted (alternatively to the exchange of the track sig-
nals).
494. The number of division marks of the
is defined by the limit frequency of f
max
60 / s min
n
n = Max. speed of the motor in RPM
max
max
/ s min
n = Min. speed of the motor in RPM
⋅ n
min
A = 4 (quadruple evaluation)
min
493 and selection of the corre-
493, the following opera-
Function
Setting
Min. Max.
1 8192
=
max
min
Fact. Sett.
1024
