5.1.4.1
The analog input signal is mapped onto a reference value as a function of the charac-
teristic. The following examples show the operation modes for an analog voltage sig-
nal. The parameter
teristic point 100% for the Y axis corresponds to the parameter
419 of 50.00 Hz in the examples
Attention! The various operation modes change the input characteristic as a function
In operation mode "1 – bipolar", the characteristic of the analog input can be freely
set by stating two characteristic points.
In operation mode "11 – unipolar", the characteristic points are displaced to the origin
of the characteristics with a negative value for the X axis.
06/05
06/05

Examples

Minimum Frequency
of the parameterized characteristic points. In the following examples, the
areas of the system of coordinates from which a characteristic point is
displaced are marked.
Y
(X2=80% / Y2=85%)
42.50Hz
-7V
-25Hz
(X1=-70% / Y1=-50%)
Y
(X2=80% / Y2=85%)
42.50Hz
-7V
-25Hz
(X1=-70% / Y1=-50%)
418 is set to the value 0.00 Hz. The charac-
Operation mode "1 – bipolar"
Characteristic point 1:
X1 = -70.00% · 10 V = -7.00 V
Y1 = -50.00% · 50.00 Hz = -25.00 Hz
Characteristic point 2:
X2 = 80.00% · 10 V = 8.00 V
Y2 = 85.00% · 50.00 Hz = 42.50 Hz
X
Tolerance band:
8V
ΔX = 2.00% · 10 V = 0.20 V
The change of direction of rotation is done
in the example at an analog input signal
of -1.44 V, with a tolerance band of ±0.20
V.
Operation mode "11 – unipolar"
Characteristic point 1:
X1 = -70.00% · 10 V = -7.00 V
Y1 = -50.00 % · 50.00 Hz = -25.00 Hz
Characteristic point 2:
X2 = 80.00% · 10 V = 8.00 V
Y2 = 85.00% · 50.00 Hz = 42.50 Hz
X
Tolerance band:
8V
ΔX = 2.00% · 10 V = 0.20 V
The characteristic point 1 has been dis-
placed to the origin. The parameter
erance band
count in this example, as no change of
sign of the reference frequency value
takes place.
Maximum Frequency
560 is not taken into ac-
