If a PC or a PLC is used as a master, the identifiers of the Rx/Tx-SDO1 can be
adapted by parameterization on the frequency inverter.
Attention! In free assignment of identifiers, there may not be any double occu-
The setting of the identifiers of the RxSDO1 is done via the parameter
Identifier
The setting of the identifiers of the TxSDO1 is done via parameter number 922.
The setting "0" results in identifier assignment according to the Predefined Connection
Set.
The second SDO channel can be deactivated via the
The identifier assignment for the second SDO channel is always to the
specification:
Identifier Rx-SDO2
Identifier Tx-SDO2
Note:
06/05
06/05
pancy !
The identifier range 129...191 may not be used as the emergency tele-
grams can be found there.
921.
Parameter
No.
Description
921 RxSDO1-Identifier
Parameter
No.
Description
922 TxSDO1-Identifier
Operation mode
0 -SDO2 deactivated
1 -SDO2 activated
= 1600 + Node-ID
= 1472 + Node-ID
In this way, firm identifiers via which communication takes place are
available for the visualization tool.
Min.
0
Min.
0
SDO2 Set Active
Function
Communication channel deactivated
Communication channel activated for the visuali-
zation tool
RxSDO1-
Setting
Max.
Fact. sett.
2047
0
Setting
Max.
Fact. sett.
2047
0
923.
27
27
