5.1.7
The monitoring of the analog input signal necessary according to the application is to
be configured via the parameter
The monitoring of the analog input signal is active independent of the release of the
frequency inverter according to the operation mode selected.
In operation mode 2, the drive mechanism is decelerated independent of the stopping
behavior set (Parameter
(shutdown and stop). If the set holding time has expired, there is a fault message. A
repeat start of the drive mechanism is possible by switching the start signal on and off
if the fault has been rectified beforehand.
Operation mode 3 defines the free stoppage of the drive mechanism, independent of
the stopping behavior selected, which is stipulated with the parameter
Mode
Attention! Monitoring of the analog input signal via the parameter
06/05
06/05

Error and warning behavior

Operation mode
0 -Off
1 -Warning < 1 V / 2 mA
2 -Shutdown < 1V / 2 mA
Fault switch-off
3 -
< 1 V / 2 mA
630.
Behavior
563 demands a check of the characteristic parameters.
Error/Warning behavior
The input signal is not monitored.
If the input signal is smaller than 1 V or 2 mA,
there is a warning message.
If the input signal is smaller than 1 V or 2 mA,
there is a warning message, the drive mechanism
is decelerated according to stopping behavior 2.
If the input signal is smaller than 1 V or 2 mA,
there is a warning and fault message and the
drive mechanism stops freely.
Operation mode
630) according to stopping behavior 2
563.
Function
Operation
Error/Warning
