This document describes the possibilities and the properties of the EM-IO-03 expan-
sion module for the frequency inverters of the ACT and ACU series of devices.
Note:
The EM-IO-03 expansion module is an optional hardware component to extend the
functionality of the frequency inverter. It enables the data exchange within the net-
work and between the components which have been directly connected, for example
control elements.
The EM-IO-03 expansion module is supported from device series ACU and as from
software version 4.1.0 of device series ACT.
The module extends the functionality of the frequency inverters of the ACT and ACU
series of devices by the following additional functions:
−
−
−
−
−
−
The EM-IO-03 expansion module has been enclosed with the frequency inverter as a
separate component and must be fitted by the user. This is described in detail in the
"Mechanical Installation" chapter.
The expansion module is assembled simply by plugging on without tools being needed
thanks to the modular set-up of the frequency inverters of the ACT and ACU series.
Warning! The assembly is done before the frequency inverter is put into operation,
The terminals of the expansion module, which are also to be plugged, enable eco-
nomical overall fitting with a safe function.
06/05
06/05

Introduction

This document exclusively describes the EM-IO-03 expansion module. It
does not provide basic information on the operation of the ACT and
ACU series frequency inverters.
CAN system bus
(CAN interface ISO-DIS 11898; CAN High Speed; max. 1 MBaud)
analog input, adjustable voltage/current input
(second bipolar analog input)
two analog outputs: one voltage output and one current output
(second and third bipolar analog output)
two digital inputs
(can be used as second incremental speed sensor input, for example)
one relay output
(make contacts)
one motor PTC connection
and only in a voltage-free state.
