5 Control inputs and outputs
5.1
5.1.1
The analog input of the EM-IO-03 expansion module can optionally be configured as a
voltage or a current input. Parameterization of the input signal is done by the defini-
tion of a linear characteristic and assignment as a
−
−
−
−
5.1.2
The analog input of the EM-IO-03 expansion module has been configured in the fac-
tory setting for a voltage signal of +/-10 V.
Switch S3 enables a switch-over of the operation mode for an analog current signal of
+/-20 mA.
Note:
06/05
06/05
Analog input EM-S1INA
General
reference value source
(can be selected via the parameter
reference percentage source
(can be selected via the parameter
actual percentage source
(can be selected via the parameter
tion x11) or
limit value source
(can be selected via the parameter
Configuration voltage/current input
Operation mode – switch S3
OFF -Voltage input
ON -Current input
With the two switches
interface is configured (refer to chapter "System Bus Interface").
Reference frequency source
Reference percentage source
Actual percentage source
Limit Source
S3
X410A
X410B
OFF (to the right) –
analog input EM-S1INA is configured for a
voltage signal.
ON (to the left) –
analog input EM-S1INA is configured for a
current signal.
S1
and S2, the bus connection of the system bus
475),
476),
478, in configura-
734...737).
S1
S2
Function
