NIBP Normal Operation

1. Press the left ARROW key on the NIBP simulator to highlight SELECT BP, then
press the ENT key. Set pressure test to 120/80 (90) and press the ENT key.
2. Select a NIBP simulation of 120/80 mmHg with a Heart rate of 60 BPM.
3. Attach the NIBP simulator to the input pressure fitting of UUT.
4. Press the INTERVAL key of the keypad until a 1 is shown in the Timer/Temp./
Interval LED of the UUT. Press the PATIENT SIZE key to select Adult size
indicator.
5. Press the Set ALARMS key to enter the alarm setting mode. Use the UP and DOWN
ARROW keys to set the Systolic Low alarm to 130 mmHg.
6. Press the Set ALARMS key again and set the Diastolic Low Alarm to 95 mmHg.
7. Press the Start NIBP key. Verify the monitor takes a measurement and the Systolic
and the Diastolic low alarms are violated. The LEDs for these parameters will blink
on and off and an alarm tone will sound for the violation. Press the MUTE Key to
silence the alarms.
8. After the fifth measurement is complete, allow the cuff to pump up. Press DEFLATE
key. Verify cuff deflates.
9. Review the data that was stored in the database, by scrolling through the patient trend
information. Use the UP and DOWN ROOM and BED keys or LED display of the
UUT and verify that the Systolic and Diastolic information is available in the LEDs
for each stored settings
10. Remove the cuff from the UUT and press the START key. Confirm that the UUT
pump runs and that it displays 8810 in the Room/Bed window within 60 seconds and
attempts another inflation. Press the DEFLATE key to stop test.

Trend Memory Initialization

1. To clear the UUT Trend Memory for all patient settings, press and hold the DELETE
INFO. key while powering up the unit.
