Isolating the Problem within the Main Unit

Problems within the main NIBP and/or SpO
supply problems and NIBP and/or SpO
even turn on, proceed to Power Supply and Battery Tests, otherwise skip to Diagnostics
Test and beyond.
1. Power Supply and Battery test: The main power supply output voltages should be
2. Perform Diagnostics Test 01 through 12. Repair or replace circuits or components that
3. Trend circuits test: Obtain a minimum of five NIBP measurements and simultaneous
3.5.3

Isolating the Problems with Optional Accessory Modules

1. Predictive Temperature Module Test: Obtain one or more temperature readings from
2. Recorder Module Test: Obtain a print out of stored data, or perform diagnostics test
3. Infrared (AccuTemp IR) temperature module test: The following paragraphs will
3.5.4

Clinical Issues with AccuTemp IR Ear Thermometer Applications

3.5.4.1

Multiple Temperature Measurements

The AccuTemp IR employs an easy and quick method to taking temperature
measurements. Because of this, it is tempting to take immediate repetitive measurements.
However, taking immediate repetitive measurements in the same ear may result in a
decrease in temperature. This is because the probe of an ear thermometer is cooler than the
ear canal and will draw the heat from the ear canal, cooling the canal slightly. Waiting a
few minutes before taking another temperature in the same ear will give the ear canal time
to recover, and the readings should be consistent with the initial measurement.
Accutorr Plus Service Manual
verified under normal instrument loads. Below are the tolerances for the voltages
shown:
fail the Diagnostic Test.
SpO and Temperature readings if the Accutorr has those options. Confirm Trend
2
storage function as explained in the operating instructions.
the optional temperature modules. They will be displayed in the temperature display
window. If the readings are not displayed, replace the temperature probe first, then the
complete module.
(#4) to verify recorder integrity. Substitute recorder with a known good device to
confirm diagnosis.
assist you to separate those clinical issues that can result in inaccurate or inconsistent
readings, as well as instrument malfunctions.
Since there are no user serviceable components (except 9V battery) inside the
AccuTemp IR, all service requests should be directed to the factory.
0070-10-0691
unit are categorized broadly into power
2
detection and display. For a monitor that will not
2
5V = 4.9 - 5.1
12.5V = 12 - 13
±15V = 14.5 - 15.5
Troubleshooting (Problem Isolation)
3 - 7
