Nibp Pump Connector, J-505; Led Backlight Connector, J-651; Communication Connector, J-603; Lcd Connector, J-8 - Datascope Accutorr Plus Service Manual

Interconnect Cables Run List
3.7.1.8
3.7.1.9
3.7.1.10
3.7.1.11
3 - 20
To Purchase, Visit Avobus.com

NIBP Pump Connector, J-505

LED
PIN # INPUT/OUTPUT
1 Output
2 Input
3 Input

LED Backlight Connector, J-651

PIN # INPUT/OUTPUT
1 Output
2 Input

Communication Connector, J-603

PIN # INPUT/OUTPUT
1 N/C
2 Input
3 Output
4 Output
5 N/C
6 Output
7 Output
8 Input
9 Output
10 Output
11 Output
12 Output
13 Input
14 Output

LCD Connector, J-8

PIN # INPUT/OUTPUT
1 Out
2 Out
3 Out
4 Out
5 Out
6 Out
or call 1-800-674-3655
DESCRIPTION
pump supply
pump return
power ground
DESCRIPTION
Min 3.4V - Max 3.6V
Return
DESCRIPTION
N/C
RS-232
RS-232
Ground
N/C
Ground
RS-232, Transmit
RS-232, Receive
Ground
Ground
+7Vdc min
RS-232 or RS-485
RS-232 or RS-485
12VDC +/- 5%@ 100mA
DESCRIPTION
Chassis Ground
ground
+5V supply (+/-5%)
View angle control -15V max
TTL, control line
TTL, control line
0070-10-0691
Repair Information
NAME
+12VF
PUMP*
P(power ground)
NAME
BL+
BL-
NAME
N/C
RTS
CTS
DGND
N/C
DGND
EXT_TXD
EXT_TXD
DGND
DGND
NCall
TXD
RXD
+12VT
NAME
CHASSIS
DGND
VCC
VEE
WR_LCD*
RD_LCD*
Accutorr Plus Service Manual
