Precautions And Guidelines

In the event that the instrument covers are removed, observe these following precautions
and general guidelines:
• Do not short component leads together.
• Perform all steps in the order given.
• Use extreme care when reaching inside the opened instrument. Do not contact exposed
metal parts which may become live.
Read through each step in the procedure so it is understood prior to beginning the step.

Test Equipment And Special Tools Required

Equipment types other than these listed may be utilized if they equal or exceed the listed
equipment performance.
• Non-Invasive Blood Pressure Simulator
• Stopwatch
• SpO Simulator
2
• RS232 Test Connector (pins 2 and 3 shorted), 9-pin male "D" and software download
port tester
• Phono plug (tip and ring shorted)
• 700 cc Dummy Cuff (P/N 0138-00-0001-01)
• Chart Paper (P/N 0683-00-0447-01)
• Water Bath, stirred, heated 80° to 120° F
• Reference Thermometer, 0.1%

Power-up Sequence, Internal Testing

1. Attach the AC power cord into the UUT rear panel AC Input module.
2. Press the ON/STANDBY key to turn the UUT On. The UUT automatically performs
internal self diagnostics. The Timer / Temp. display starts a count down from 20. This
is the initial software verification. Allow the unit to complete the start up sequence
until there is a single LED light steadily illuminated above the Patient Setup key.
After the initial power up sequence, "a" is displayed in the bed LED, and "0" is
displayed in the Room LEDs.
3. Press the ON/STANDBY key to turn the UUT off.
