Power Supply Header, J-502

PIN # DESCRIPTION
1 +5V Supply
2 +5V Supply
3 +5V Return
4 +5V Return
5 +15V Supply
6 -15V Supply
7 +/- 15V Return
8 +12V Return
9 +12V Supply
10 Standby
11 AC ON
12 +12V -15V ON
13 OFF/ON
14 Charge Off
J-2 Keypad Connector
PIN # FUNCTION
1 Battery LED
2 Interval LED
3 Neonatal LED
4 Pediatric LED
5 Adult LED
6 Memory Full LED
7 NIBP Ready LED
8 Print LED
9 Mute LED
10 Data Scan LED
11 AC On LED
