Calibration
5.5.14
Accutorr Plus Service Manual
To Purchase, Visit Avobus.com
Overpressure Transducer Verification <12c, 12a, 12b>
This test verifies that the overpressure transducer is calibrated correctly. Calibration is
checked in the Low level pressure mode so that the limit displayed in the MAP window
should say 158 mmHg (±1). If it does not, the transducer needs to be calibrated by
proceeding to 5.5.16 "Overpressure Transducer Calibration" on page 5-15. The
overpressure transducer should also be verified in the High and Mid level pressure modes.
1. Select diagnostic test "12" (Room) "a" (Bed). Low Limit
2. Press the START NIBP key to start the test.
3. Verify that the overpressure value displayed in the MAP LEDs is 158 mmHg (±1).
4. Repeat steps 1 through 3, but select test "12" "c" to check overpressure limit, 315
mmHg (±15); and test "12" "b" for Mid level overpressure limit, 210 mmHg (±10).
5. Press the DEFLATE key to exit this test.
