Repair Information
3.7

Interconnect Cables Run List

3.7.1

Interface Specifications, Connectors and Functions.

3.7.1.1

Connector to LED / Tone PCB, J-2

PIN #
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
Accutorr Plus Service Manual
INPUT/OUTPUT DESCRIPTION
Vcc return
Output Reset
Input/Output Damped Data Bus D(0)
Input Write Recorder
Vcc return
FPGA Not Done
Input/Output Damped Data Bus D(1)
Output Read/ Write
Vcc return
Output LDS
Input/Output Damped Data Bus D(2)
Output Chip Select I/O
Vcc return
Input Write Delay
Input/Output Damped Data Bus D(3)
Input ST Watchdog
Vcc return
Input LCD Angle
Input/Output Damped Data Bus D(4)
Input LCD Angle Feed Back
Vcc return
Input LCD Angle Reference
Input/Output Damped Data Bus D(5)
Output TONE
Vcc return
N/C N/C
Input/Output Damped Data Bus D(6)
Input Read Configure
Vcc return
N/C N/C
Input/Output Damped Data Bus D(7)
+5V Supply
Vcc return
+5V Supply
0070-10-0691
Interconnect Cables Run List
NAME
D(digital ground)
RST_CONN*
D_DAMP_CONN(0)
WR_RECD*
D(digital ground)
FPGA_NOT DONE*
D_DAMP_CONN(1)
R/W_CONN*
D(digital ground)
LDS*
D_DAMP_CONN(2)
CS_IO*
D(digital ground)
WR_DLY*
D_DAMP_CONN(3)
ST_WDOG*
D(digital ground)
LCD_ANGLE
D_DAMP_CONN(4)
LCD_ANGLE_FB
D(digital ground)
LCD_REF
D_DAMP_CONN(5)
TONE
D(digital ground)
N/C
D_DAMP_CONN(6)
RE_CONFG*
D(digital ground)
N/C
D_DAMP_CONN(7)
VCC
D(digital ground)
VCC
3 - 15
