Introduction

5.1

Introduction

The Accutorr Plus is a state of the art device employing digital determination and
verification systems to obtain superior performance for the life of the product. Most
function calibration constants are written into the operating software, therefore, for the
most part, there are no means to calibrate or adjust system functions. The instrument
contains extensive Service Diagnostics that will, in most cases, isolate a malfunction to
the lowest serviceable module.
NOTE:
All internal verifications and adjustments should be performed with the internal battery
disconnected. Operate the UUT on the main power supply. This will insure a reliable
power source for the test, as well as providing a measure of safety in case of accidental
overload of the power source. To re-initialize the low battery detector circuits, reconnect
the battery at the conclusion of all tests while the UUT is on A.C. power source. Reset the
real-time clock and date, if required.
5.1.1

Status and Error Code Table

The Accutorr Plus uses the various displays on the front panel to display the operational
status. Error codes listed below can generally be resolved by the user however, error codes
with an asterisk (*) may require resolution by a qualified technical service person.
5.1.1.1

Error Codes

Table 5-1
TYPE
NIBP
TEMP
(PTM)
5 - 2
This procedure refers to this instrument as the
UUT (Unit Under Test).
CODE DESCRIPTION
8810 Retry - Unable to
Measure
8811 Retry - Pump
Higher
8812 Stop - Cuff
Overpressure
8813 Stop - Unable to
Measure
8830 Check Probe
8831 Replace Probe
0070-10-0691
REASON
Motion artifact, cycle time-out, weak pulsations or
no pulsations. A triple beep tone is generated.
Insufficient cuff pressure. A triple beep tone is
generated.
Excessive cuff pressure detected by the software.
A triple beep tone is generated.
4 successive measurement attempts failed. A triple
beep tone is generated.
Tissue contact may have been lost.
Defective probe or connection.
