Service Diagnostics
5.5.2

Software Version Test (0a, 0b)

This test displays the installed software version (s) in the monitor. The results are
displayed in the read outs illustrated in Figure 5-1 on page 5-6.
Installed Software
Example: AO1.02
Software Module
Example: ACM
software identifier
FIGURE 5-1 - Software Version Test
Confirm that the ROOM number is at "0"; otherwise use the "ROOM/BED" key to select
the "ROOM", and the UP/DOWN keys to set Room number to "0".
Press ROOM/BED key to select BED. Use the UP/DOWN ARROW keys to select test
"a" or "b". Monitors without SpO
Press ROOM/BED again to lock in selection.
Press the START NIBP key.
Press the DEFLATE key until a beep is heard. This allows a selection of the next test.
Repeat process for test "b".
Table 5-2
DESCRIPTION OF SOFTWARE MODULE
ACM Runtime Software Version
ACM Boot Software Version
5 - 6
Selection
Runtime
0070-10-0691
option may not display results for tests "0c" and "0d".
2
TEST ROOM
NUMBER
0
0
Calibration
SUB TEST
PATIENT BED
LETTER
a
b
Accutorr Plus Service Manual
