Disassembly Instructions

3.6

Disassembly Instructions

CAUTION:
1. Power down the Accutorr Plus and remove the AC power cable.
2. Remove all cables and hoses from the front and rear of the instrument.
3. Remove temperature measuring module and recorder module, if equipped.
3.6.1

Removal of the Rear Housing

1. Place the Accutorr Plus with the display side down, onto a protective surface.
NOTE:
2. Remove the 4 screws from the corners of the back housing recess and the two screws
3. Slowly lift the rear housing up and place in a safe location.
4. Disconnect battery connector (J4) from the Power Supply board.
3.6.2

Removal of the Front Bezel

1. Place the front housing with the display side down, onto a protective surface.
2. Disconnect the SpO
3. Slowly separate the assembly up and away from the front housing.
3.6.3

Removal of the Keyboard Assembly

1. Place the instrument with the display side down, onto a protective surface.
2. Remove the Front Bezel, as described above.
3. Remove the screws (6) securing the Keyboard Assembly and lift the keyboard,
3.6.4

Removal of the LED/Tone board

1. Remove front bezel and keyboard.
2. Disconnect cable from J4, the speaker connection.
3. Remove the four screws holding the circuit board. Pull circuit board forward,
3 - 10
The Inside Of This Instrument Contains Static
Sensitive Components. Use correct static
protection safeguards.
Special care should be taken to insure that the
front panel and glare screen are not scratched.
in the center channel of the rear case.
ribbon cable (J3) from the SpO
2
from the NIBP front panel connector.
supporting and separating the connector to the LED/Tone board.
disconnecting the rear J-1 connector.
0070-10-0691
Repair Information
circuit board and the tubing
2
Accutorr Plus Service Manual
