Interconnect Cables Run List
PIN #
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
3 - 16
INPUT/OUTPUT DESCRIPTION
Input/Output Damped Data Bus D(8)
N/C N/C
Vcc return
+5V Supply
Output Clock O
+5V Supply
Vcc return
Input Keypad Data Bus (D0)
Output Damped Address(2)
N/C N/C
Vcc return
N/C N/C
Output Damped Address(3)
Input Keypad Data Bus (D3)
Vcc return
N/C N/C
Output Damped Address(4)
N/C N/C
Vcc return
N/C N/C
Output Damped Address(5)
N/C N/C
Vcc return
Output AC ON
Output Damped Address(6)
Input Switched ON/OFF
Vcc return
N/C N/C
Output Damped Address(7)
N/C N/C
Output Vcc return
N/C N/C
N/C N/C
Output AC LED ON
+5V Supply
Input High Low
+5V Supply
Input LCD Unit
N/C N/C
N/C N/C
0070-10-0691
Repair Information
NAME
D_DAMP_CONN(8)
N/C
D(digital ground)
VCC
CLKO_CONN
VCC
D(digital ground)
KEYD0
A_DAMP_CONN(2)
N/C
D(digital ground)
N/C
A_DAMP_CONN(3)
KEYD3
D(digital ground)
N/C
A_DAMP_CONN(4)
N/C
D(digital ground)
N/C
A_DAMP_CONN(5)
N/C
D(digital ground)
ACON*
A_DAMP_CONN(6)
ON/OFFSW*
D(digital ground)
N/C
A_DAMP_CONN(7)
N/C
D(digital ground)
N/C
N/C
ACON_LED
VCC
HIGH/LOW*
VCC
LCD_UNIT*
N/C
N/C
