Power Supply Connectors; Ac Input Connector, J-2; Dc Output Connector, J-3 - Datascope Accutorr Plus Service Manual

Repair Information
PIN #
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
3.7.2

Power Supply Connectors

3.7.2.1

AC input connector, J-2

PIN #
1
2
3
3.7.2.2

DC output connector, J-3

PIN #
1
2
3
4
5
Accutorr Plus Service Manual
INPUT/OUTPUT DESCRIPTION
Out TTL, control line
Out TTL, address line
In -10V supply
Out TTL, LCD reset
In/Out TTL, data line
In/Out TTL, data line
In/Out TTL, data line
In/Out TTL, data line
In/Out TTL, data line
In/Out TTL, data line
In/Out TTL, data line
In/Out TTL, data line
Out ground
N/C N/C
Out TTL Level
Out TTL Level
Out TTL Level
Out TTL Level
Out +15VDC
Out -15VDC
FUNCTION
AC Ground
N/C (pin removed)
AC Neutral
FUNCTION
+5 V
+5 V
Common
Common
+15 V
0070-10-0691
Interconnect Cables Run List
NAME
CS_LCD*
A_DAMP_CONN<2>
-10V
RESETSRV*
D_DAMP_CONN<0>
D_DAMP_CONN<1>
D_DAMP_CONN<2>
D_DAMP_CONN<3>
D_DAMP_CONN<4>
D_DAMP_CONN<5>
D_DAMP_CONN<6>
D_DAMP_CONN<7>
DGND
N/C
A_DAMP_CONN<3>
A_DAMP_CONN<4>
DSP_CONT*
A_DAMP_CONN<5>
+15VV
-15VV
PIN # FUNCTION
4 N/C (pin removed)
5 AC Hot
PIN # FUNCTION
8 Common
9 +12.5 V
10 STDBY
11 ACON*
12 +12-15ON*
3 - 21
