Specifications
2.1.7
2.1.8
Accutorr Plus Service Manual
To Purchase, Visit Avobus.com
®
Nellcor SpO
2
Range:
Display Resolution:
SpO2 Response Time:
Display Update:
Calibration:
Accuracy*:
Pulse Rate Range:
* Neonatal accuracy specifications are based upon testing the N-3000 and N-25 neonatal sensors on
healthy adult volunteers in induced hypoxia studies, in the range of 70 - 100% SpO2. The specified accu-
racy also takes into account published literature which predicts that there may be a small difference in % of
SpO2 reported by the oximeter when measurements from adult and fetal blood with 100% fetal hemoglobin
are compared. Fetal hemoglobin is present in concentrations varying from 10% to 90% in neonatal blood,
and this percentage declines over time. As the percentage of fetal hemoglobin in neonatal blood declines,
the theoretical effect on accuracy due to this source is reduced.
®
Masimo SpO
2
Range:
Display Resolution:
Display Update:
SpO2 Accuracy Saturation during No Motion Conditions
Adults / Pediatrics:
Neonates (LNOP/LNCS):
SpO2 Accuracy Saturation during Motion Conditions
2
Adults / Pediatrics :
3
Neonates (LNOP):
3
Neonates (LNCS):
SpO Response Time:
2
or call 1-800-674-3655
70-100% SpO
2
1% SpO
2
4.5 to 6.5 seconds
Less than 4 seconds
Factory Calibrated to Functional Saturation
± 2 digits from 70 - 100% SpO
± 3 digits from 70 - 100% SpO
<70% unspecified
21 to 249 BPM
70-100% SpO2
1% SpO
2
< 4 seconds
70% to 100% ± 2 digits
<70% unspecified
70% to 100% ± 3 digits
6
70% to 100% ± 3 digits
<70% unspecified
70% to 100% ± 4 digits
70% to 100% ± 3 digits
<70% unspecified
10 secs (Display Averaging Time is not
user-selectable for Masimo ® . It will be set to
the default value of 8 seconds.)
0070-10-0691
Performance Specifications
- Adult
2
- Neonates
2
1
5
2 - 3
