  • Page 1 ® ® Advanced Test Equipment Rentals Advanced Test Equipment Rentals www.atecorp.com 800-404-ATEC (2832) www.atecorp.com 800-404-ATEC (2832)
  • Page 2 Instruction Manual P6022 Current Probe 070-0948-04 Warning The servicing instructions are for use by qualified personnel only. To avoid personal injury, do not perform any servicing unless you are qualified to do so. Refer to all safety summaries prior to performing service.
  • Page 3 Copyright © Tektronix, Inc. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved. Tektronix, Inc., P.O. Box 500, Beaverton, OR 97077...
  • Page 4 Tektronix, shipping charges prepaid, and with a copy of customer proof of purchase. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located.

  • Page 6: Table Of Contents

    ..... . P6022 Test Record ........
  • Page 7 Replaceable Electrical Parts Parts Ordering Information ....... Using the Replaceable Parts List .

  • Page 8: General Safety Summary

    Do Not Operate with Suspected Failures If you suspect there is damage to this product, have it inspected by qualified service personnel. Do Not Immerse in Liquids Clean the probe using only a damp cloth. Refer to cleaning instructions. P6022 Instruction Manual...
  • Page 9 Safety Terms and Symbols Terms in This Manual These terms may appear in this manual: WARNING Warning statements identify conditions or practices that could result in injury or loss of life. CAUTION Caution statements identify conditions or practices that could result in damage to this product or other property.

  • Page 10: Service Safety Summary

    P6022 Current Probe Service Safety Summary Only qualified personnel should perform service procedures. Read this Service Safety Summary and the General Safety Summary before performing any service procedures. Do Not Service Alone Do not perform internal service or adjustments of this product unless anoth- er person capable of rendering first aid and resuscitation is present.

  • Page 11: Description

    6:00 a.m. - - 5:00 p.m. Pacific time This phone number is toll free in North America. After office hours, please leave a voice mail message. Outside North America, contact a Tektronix sales office or distributor; see the Tektronix web site for a list of offices. Safety...

  • Page 12: Operator Information

    Your P6022 is shipped with the following accessories: This instruction manual — Read these instructions to familiarize your- self with the features, specifications, and operation of the P6022 current probe. 6-inch ground lead — Use the 6-inch ground lead to ground the shield around the probe transformer at the probe end of the cable.

  • Page 13: Operating Considerations

    Considerations Features and Controls Sensitivity Control — The P6022 termination has a control that allows you to select probe sensitivity. The switch has two positions: 1 mA/mV and 10 mA/mV. When the control is in the 1 mA/mV position, the oscillo- scope displays 1 mV for every 1 mA of current in the circuit under test.

  • Page 14: Insertion Impedance

    When you insert a conductor into the probe, you add impedance to the circuit you are measuring. This additional impedance affects signals; this is particularly important if you are measuring fast rise times. Figure 2 illustrates the equivalent circuit with additional impedance introduced by the P6022. 0.6 H 0.2 nH .025 Ω...

  • Page 15: Probe Shielding

    Operator Information Probe Shielding The P6022 is shielded to minimize the effect of external magnetic fields. However, strong fields can interfere with the current signal being measured. If you suspect that an external field is interfering with your measurement, remove the probe from the conductor, but keep it in the same location as when you made the suspect measurement.
  • Page 16 Operator Information P6022 Instruction Manual...

  • Page 17: Service Information

    Service Information This section lists the various warranted characteristics that describe the Warranted P6022 Current Probe. Included are warranted electrical and environmental Characteristics characteristics. Warranted characteristics are described in terms of quantifiable performance limits that are warranted. The electrical characteristics listed in Table 1 apply under the following...
  • Page 18 <10 ms and <25% duty factor. 100 A 20 A 10 A AMPS 10mA/mV 1 mA/mV 0.1A 100 Hz 1 kHz 10 kHz 1 MHz 10 MHz 100 MHz FREQUENCY Figure 3: Probe and Termination Input Current vs. Frequency Derating P6022 Instruction Manual...
  • Page 19 Equipment is usually cord-connected CAT I Secondary (signal level) or battery oper- ated circuits of electronic equipment Pollution Degree 2 Do not operate in environments where conductive pollutants may be present. P6022 Instruction Manual...

  • Page 20: Typical Characteristics

    Service Information This section lists the various typical characteristics that describe the P6022 Typical Current Probe. Included are typical electrical and mechanical characteris- Characteristics tics. Typical characteristics are described in terms of typical or average perfor- mance. Typical characteristics are not warranted.
  • Page 21 ≈48 gm Termination 1.7 oz Termination L 3.47” 88 mm W 1.10” 28 mm H 0.86” 22 mm Probe body L 6.0” 152 mm W 0.4” 10 mm H 0.6” 15 mm Maximum conductor diameter 0.141” 3.58 mm P6022 Instruction Manual...

  • Page 22: Circuit Description

    As indicated on the probe body, the turns ratio of the P6022 is 50:1. This refers to the number of windings in the secondary of the probe transformer.

  • Page 23: Probe Performance

    This section provides procedures to check the performance of the P6022, or to calibrate it. These procedures require the equipment listed in Table 7 on page 14. Specifications given are the minimum necessary for accuracy. If equipment is substituted, it must meet or exceed the specifications of the recommended equipment.
  • Page 24 Sinewave voltage into 50 Ω (100 A), Wavetek 9100 with option 100:250, or 935 Hz to 120 MHz Tektronix SG 5030, SG 503 1.5X, flatness Digital multimeter (DMM) 5 1/2 digits or better Keithley 2000, or HP 3458A 50 kHz ≤ 0.5%...

  • Page 25: Performance Verification

    Figure 4: Midband accuracy test setup Step 1: Set the P6022 termination sensitivity to 1 mA/mV. Step 2: Connect the Leveled Sinewave Output of the calibration genera- tor to a BNC “T”. Connect one branch of the BNC “T” to the calibration fixture.

  • Page 26: Check Low Frequency Response

    Service Information Step 7: Connect the P6022 termination and probe to the BNC-to-dual banana adapter. Step 8: Connect the probe to the calibration fixture. Step 9: Record the DMM output as M2. Step 10: Calculate the % of error. Itest = M1 50 Ω...
  • Page 27 Step 13: Record the results in the test record on page 20 and compare the results against the low frequency specification on page 20. Step 14: Set the P6022 termination sensitivity to 10 mA/mV. Step 15: Set the Leveled Sinewave Output of the calibration generator to 50 kHz and an amplitude of 5 V Step 16: Measure and record the DMM output as M3 in Table 1---1.

  • Page 28: Check High Frequency Bandwidth

    Step 1: Set the P6022 termination sensitivity to 1 mA/mV. Step 2: Connect the calibration fixture to the Leveled Sinewave Output of the calibration generator. Step 3: Connect the P6022 termination and probe to CH1 of the oscillo- scope. Step 4: Set the oscilloscope Vertical Deflection to 20 mV/div.
  • Page 29 Step 15: Record the results in the test record on page 20 and compare the results against the high frequency specification on page 20. Step 16: Set the P6022 termination sensitivity to 10 mA/mV. Step 17: Set the oscilloscope Vertical Deflection to 2 mV/div.

  • Page 30: P6022 Test Record

    Service Information P6022 Test Record Photocopy this form and use it to record the performance test results. P6022 test record Instrument Serial Number: Certificate Number: Temperature: Relative Humidity %: Date of Calibration: Technician: Range, Performance test mA/mV Minimum Measured/calculated Maximum...

  • Page 31: Adjustment Procedure

    Step 2: Set the fast rise output to maximum (1 V Step 3: Connect the P6022 cable BNC connector to the termination. Step 4: Connect the P6022 termination to the oscilloscope Ch 1 input. Step 5: Set the P6022 termination sensitivity to 1 mA/mV.
  • Page 32 The R10 adjustment affects the aberrations of both the 1mA/mV and 10 mA/mV termination setting along with the high frequency re- sponse. Readjust the high frequency response if it fails. (back) Probe P6022 AC CURRENT PROBE TEKTRONIX, INC. 50 TURNS Calibration fixture...

  • Page 33: Maintenance

    Refer to Figure 8 on page 24. CAUTION To avoid degrading the probe’s performance, do not touch the polished mating surfaces of the transformer after cleaning. P6022 Instruction Manual...
  • Page 34 Step 6: Lift the back of the return spring retainer out of the holder. Step 7: Remove the slide switch, spring retainer, and the top of the transformer as a unit. Notice the orientation of the movable portion of the transformer in the slide. P6022 Instruction Manual...

  • Page 35: Repairing The Probe

    Step 2: Using a heat sink, unsolder the leads from the defective con- nector. Step 3: Unscrew and remove the defective connector. Step 4: Replace the defective connector with the new one. Step 5: Screw and solder the new connector back in place. P6022 Instruction Manual...
  • Page 36 Step 5: Replace the circuit board by reversing the above procedure. Step 6: Align the switch with the slider in the front cover and replace the front cover. P6022 Instruction Manual...

  • Page 37: Replaceable Electrical Parts

    Replaceable Electrical Parts Replacement parts are available from or through your local Tektronix, Inc. Parts Ordering service center or representative. Information Changes to Tektronix instruments are sometimes made to accommodate improved components as they become available and to give you the benefit of the latest circuit improvements.
  • Page 38 A2 with its subassemblies and parts). Chassis-mounted parts have no assembly number prefix and are located at the end of the electrical parts list. Tektronix Part No. (column 2 of the parts list) Indicates part number to be used when ordering replacement part from Tektronix.
  • Page 39 Indicates the code number of the actual manufacturer of the part. (Code to name and address cross reference can be found immediately after this page.) Mfr. Part No. (column 7 of the parts list) Indicates actual manufacturer’s part number. P6022 Instruction Manual...
  • Page 40 Name & Description Mfr. Part No. Number Part No. Effective Dscont Code 670--- 1112--- 00 CIRCUIT BD ASSY:PROBE 80009 670111200 011--- 0106--- 00 TERMN,COAXIAL:P6022 80009 011010600 670--- 1112--- 00 CIRCUIT BD ASSY:PROBE 80009 670111200 A1C10 283--- 0157--- 00 CAP ,FXD,CER DI:7PF,5%,50V 04222...
  • Page 41 A1L10 A1C10 A1R10 A1T14 Figure 9: P6022 Probe Component Location A2L26 A2C26 A2C37 A2SW30 A2C21 A2R33 A2R37 A2R26 A2L28 A2R29 A2C28 A2R28 A2R39 A2R31 A2R34 A2L33 A2C29 A2R36 A2R35 Figure 10: P6022 Termination Component Location P6022 Instruction Manual...
  • Page 42 TUCSON AZ 85740--- 7144 PO BOX 37144 79727 C --- W INDUSTRIES 130 JAMES WAY SOUTHAMPTON PA 18966--- 3818 80009 TEKTRONIX INC 14150 SW KARL BRAUN DR BEAVERTON OR 97077--- 0001 PO BOX 500 91637 DALE ELECTRONICS INC 2064 12TH AVE...

  • Page 43: Replaceable Mechanical Parts

    Replaceable Mechanical Parts This section contains a list of the mechanical parts that are replaceable for the P6022. Use this list to identify and order replacement parts. Replacement parts are available from or through your local Tektronix, Inc. Parts Ordering service center or representative.
  • Page 44 Serial No. Mfr. Part No. Effective Dscont 12345 Name & Description Code Mfr. Part No. 11 --- --- --- --- --- --- --- --- --- P6022,PROBE,CURRENT:120 MHZ,100A,5FT W/TERM --- 1 204--- 0360--- 01 .BODY,PROBE:UPPER 80009 204036001 --- 2 214--- 0581--- 00 .BALL,DETENT:0.062 DIA STEEL...
  • Page 45 Figure 11: P6022 Exploded View P6022 Instruction Manual...
  • Page 46 2100 EARLYWOOD DR FRANKLIN IN 46131 PO BOX 547 8X345 NORTHWEST SPRING & MFG CO 5858 WILLOW LANE LAKE OSWEGO OR 97034--- 5343 80009 TEKTRONIX INC 14150 SW KARL BRAUN DR BEAVERTON OR 97077--- 0001 PO BOX 500 Replaceable Mechanical Parts...

  • Page 47: Index

    6 inch, 2 current vs. frequency derating, 8 grounding the probe, 2, 4 oscilloscope, 1 impedance, 1 input connectors, 1 use with, 1–2 DC saturation, maximum, 10 high frequency response, 2, 18–19, 20 direction of current flow, 3 P6022 Instruction Manual...
  • Page 48 27 test equipment, 14 mechanical, 33 oscilloscope settings, 21 performance verification, test Record, Test Record, Performance Verification, P6022, 20 P6022, 20 safety physical specifications, 11 operator information, iii tilt, 10 cable length, 11 service information, v, 13...
