How To Install; How To Get Started - Danfoss VLT AutomationDrive FC 300 Operating Instructions Manual

How to Install

About How to Install
This chapter covers mechanical and electrical installations to and from power terminals and control card
terminals.
Electrical installation of options is described in the corresponding Instructions and Design Guide
MG33.BX.YY.

How to Get Started

FC 300 AutomationDrive is designed to achieve a
quick and EMC-correct installation by following
the steps described below.
Read the safety instructions before in-
stalling the unit.
Mechanical Installation
• Mechanical mounting
Electrical Installation
• Connection to Mains and Protecting Earth
• Motor connection and cables
• Fuses and circuit breakers
• Control terminals - cables
Quick setup
• Local Control Panel, LCP
• Automatic Motor Adaptation, AMA
• Programming
Frame size is depending on enclosure type, power
range and mains voltage
How to Install
Diagram showing basic installation including mains, mo-
tor, start/stop key, and potentiometer for speed adjust-
ment.
