Danfoss VLT AutomationDrive FC 300 Operating Instructions Manual page 74

Speed control range (open loop)
Speed control range (closed loop)
Speed accuracy (open loop)
Speed accuracy (closed loop), depending on resolution of feedback de-
vice
All control characteristics are based on a 4-pole asynchronous motor
Surroundings:
Enclosure
Vibration test
Max. relative humidity
Aggressive environment (IEC 60068-2-43
3)
Ambient temperature
1) Only for ≤ 3.7 kW (200 - 240 V), ≤ 7.5 kW (400 - 480/ 500 V)
2) As enclosure kit for ≤ 3.7 kW (200 - 240 V), ≤ 7.5 kW (400 - 480/ 500 V)
3) Derating for high ambient temperature, see special conditions in the Design Guide
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
Maximum altitude above sea level without derating
Derating for high altitude, see special conditions in the Design Guide
EMC standards, Emission
EMC standards, Immunity
See section on special conditions in the Design Guide
Protection and Features:
• Electronic thermal motor protection
against overload.
• Temperature monitoring of the heatsink
ensures that the frequency converter trips
if the temperature reaches 95 °C ± 5°C.
An overload temperature cannot be reset
until the temperature of the heatsink is
below 70 °C ± 5°C (Guideline - these tem-
peratures may vary for different power
sizes, enclosures etc.).
• The frequency converter is protected
against short-circuits on motor terminals
U, V, W.
• If a mains phase is missing, the frequency
converter trips or issues a warning (de-
pending on the load).
• Monitoring of the intermediate circuit
voltage ensures that the frequency con-
verter trips if the intermediate circuit volt-
age is too low or too high.
74
General Specifications
IP 20
5% - 95%(IEC 721-3-3; Class 3K3 (non-condensing) during operation
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
MG.33.A8.02 - VLT is a registered Danfoss trademark
1:100 of synchronous speed
1:1000 of synchronous speed
30 - 4000 rpm: error ±8 rpm
0 - 6000 rpm: error ±0.15 rpm
1) 2)
/ Type 1, IP 21 / Type 1, IP 55/ Type 12, IP 66
Max. 50 °C (24-hour average maximum 45 °C)
EN 61800-3, EN 61000-6-3/4, EN 55011
EN 61800-3, EN 61000-6-1/2,
• The frequency converter constantly
checks for critical levels of internal tem-
perature, load current, high voltage on
the intermediate circuit and low motor
speeds. As a response to a critical level,
the frequency converter can adjust the
switching frequency and/ or change the
switching pattern in order to ensure the
performance of the drive.
1.0 g
class H 5
2
0 °C
- 10 °C
-25 - +65/70 °C
1000 m
