4-** Limits / Warnings
Par. Parameter description
No. #
4-1* Motor Limits
4-10 Motor Speed Direction
4-11 Motor Speed Low Limit [RPM]
4-12 Motor Speed Low Limit [Hz]
4-13 Motor Speed High Limit [RPM]
4-14 Motor Speed High Limit [Hz]
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
4-18 Current Limit
4-19 Max Output Frequency
4-2* Limit Factors
4-20 Torque Limit Factor Source
4-21 Speed Limit Factor Source
4-3* Motor Fb Monitor
4-30 Motor Feedback Loss Function
4-31 Motor Feedback Speed Error
4-32 Motor Feedback Loss Timeout
4-5* Adj. Warnings
4-50 Warning Current Low
4-51 Warning Current High
4-52 Warning Speed Low
4-53 Warning Speed High
4-54 Warning Reference Low
4-55 Warning Reference High
4-56 Warning Feedback Low
4-57 Warning Feedback High
4-58 Missing Motor Phase Function
4-6* Speed Bypass
4-60 Bypass Speed From [RPM]
4-61 Bypass Speed From [Hz]
4-62 Bypass Speed To [RPM]
4-63 Bypass Speed To [Hz]
52
How to Programme
Default value (SR -
Size Related)
All set-ups
SR All set-ups
SR All set-ups
SR All set-ups
SR All set-ups
160.0 % All set-ups
100.0 % All set-ups
SR All set-ups
132.0 Hz All set-ups
[0] No function All set-ups
[0] No function All set-ups
[2] Trip All set-ups
300 RPM All set-ups
0.05 s All set-ups
0.00 A All set-ups
ImaxVLT (P1637) All set-ups
0 RPM All set-ups
(P413) All set-ups
-999999.999 All set-ups
999999.999 All set-ups
-999999.999 All set-ups
999999.999 All set-ups
[1] On All set-ups
SR All set-ups
SR All set-ups
SR All set-ups
SR All set-ups
MG.33.A8.02 - VLT is a registered Danfoss trademark
4-set-up FC 302 Change
only during
operation
FALSE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
FALSE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
Conver- Type
sion
index
- Uint8
67 Uint16
-1 Uint16
67 Uint16
-1 Uint16
-1 Uint16
-1 Uint16
-1 Uint32
-1 Uint16
- Uint8
- Uint8
- Uint8
67 Uint16
-2 Uint16
-2 Uint32
-2 Uint32
67 Uint16
67 Uint16
-3 Int32
-3 Int32
-3 Int32
-3 Int32
- Uint8
67 Uint16
-1 Uint16
67 Uint16
-1 Uint16
