17-** Motor Feedb.Option
Par. Parameter description
No. #
17-1* Inc. Enc. Interface
17-10 Signal Type
17-11 Resolution (PPR)
17-2* Abs. Enc. Interface
17-20 Protocol Selection
17-21 Resolution (Positions/Rev)
17-24 SSI Data Length
17-25 Clock Rate
17-26 SSI Data Format
17-34 HIPERFACE Baudrate
17-5* Resolver Interface
17-50 Poles
17-51 Input Voltage
17-52 Input Frequency
17-53 Transformation Ratio
17-59 Resolver Interface
17-6* Monitoring and App.
17-60 Feedback Direction
17-61 Feedback Signal Monitoring
64
How to Programme
Default value (SR - 4-set-up
Size Related)
[1] RS422 (5V TTL) All set-ups
1024 All set-ups
[0] None All set-ups
SR All set-ups
13 All set-ups
SR All set-ups
[0] Gray code All set-ups
[4] 9600 All set-ups
2 1 set-up
7.0 V 1 set-up
10.0 kHz 1 set-up
0.5 1 set-up
[0] Disabled All set-ups
[0] Clockwise All set-ups
[1] Warning All set-ups
MG.33.A8.02 - VLT is a registered Danfoss trademark
FC 302 Change Conver-
only during sion
operation index
FALSE -
FALSE 0
FALSE -
FALSE 0
FALSE 0
FALSE 3
FALSE -
FALSE -
FALSE 0
FALSE -1
FALSE 2
FALSE -1
FALSE -
FALSE -
TRUE -
Type
Uint8
Uint16
Uint8
Uint32
Uint8
Uint16
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
