Par.
Parameter description
No. #
1-6* Load Depen. Setting
Low Speed Load Compensa-
1-60
tion
High Speed Load Compensa-
1-61
tion
1-62 Slip Compensation
Slip Compensation Time Con-
1-63
stant
1-64 Resonance Dampening
Resonance Dampening Time
1-65
Constant
1-66 Min. Current at Low Speed
1-67 Load Type
1-68 Minimum Inertia
1-69 Maximum Inertia
1-7* Start Adjustments
1-71 Start Delay
1-72 Start Function
1-73 Flying Start
1-74 Start Speed [RPM]
1-75 Start Speed [Hz]
1-76 Start Current
1-8* Stop Adjustments
1-80 Function at Stop
Min Speed for Function at
1-81
Stop [RPM]
Min Speed for Function at
1-82
Stop [Hz]
1-83 Precise Stop Function
1-84 Precise Stop Counter Value
Precise Stop Speed Compen-
1-85
sation Delay
1-9* Motor Temperature
1-90 Motor Thermal Protection
1-91 Motor External Fan
1-93 Thermistor Resource
1-95 KTY Sensor Type
1-96 KTY Thermistor Resource
1-97 KTY Threshold level
48
How to Programme
Default value (SR -
4-set-up
Size Related)
100 %
All set-ups
100 %
All set-ups
SR
All set-ups
0.10 s
All set-ups
100 %
All set-ups
5 ms
All set-ups
100 %
All set-ups
[0] Passive load
All set-ups
SR
All set-ups
SR
All set-ups
0.0 s
All set-ups
[2] Coast/delay time All set-ups
[0] Disabled
All set-ups
SR
All set-ups
SR
All set-ups
0.00 A
All set-ups
[0] Coast
All set-ups
SR
All set-ups
SR
All set-ups
[0] Precise ramp stop All set-ups
100000
All set-ups
10 ms
All set-ups
[0] No protection
All set-ups
[0] No
All set-ups
[0] None
All set-ups
[0] KTY Sensor 1
All set-ups
[0] None
All set-ups
80 °C
1 set-up
MG.33.A8.02 - VLT is a registered Danfoss trademark
FC 302
Change
Conver-
only
during
sion
operation
index
TRUE
0
TRUE
0
TRUE
0
TRUE
-2
TRUE
0
TRUE
-3
x
TRUE
0
x
TRUE
-
x
FALSE
-4
x
FALSE
-4
TRUE
-1
TRUE
-
FALSE
-
TRUE
67
TRUE
-1
TRUE
-2
TRUE
-
TRUE
67
TRUE
-1
FALSE
-
TRUE
0
TRUE
-3
TRUE
-
TRUE
-
TRUE
-
x
TRUE
-
x
TRUE
-
x
TRUE
100
Type
Int16
Int16
Int16
Uint16
Uint16
Uint8
Uint8
Uint8
Uint32
Uint32
Uint8
Uint8
Uint8
Uint16
Uint16
Uint32
Uint8
Uint16
Uint16
Uint8
Uint32
Uint8
Uint8
Uint16
Uint8
Uint8
Uint8
Int16
