14-** Special Functions
Par. Parameter description
No. #
14-0* Inverter Switching
14-00 Switching Pattern
14-01 Switching Frequency
14-03 Overmodulation
14-04 PWM Random
14-1* Mains On/Off
14-10 Mains Failure
14-11 Mains Voltage at Mains Fault
14-12 Function at Mains Imbalance
14-2* Trip Reset
14-20 Reset Mode
14-21 Automatic Restart Time
14-22 Operation Mode
14-23 Typecode Setting
14-25 Trip Delay at Torque Limit
14-26 Trip Delay at Inverter Fault
14-28 Production Settings
14-29 Service Code
14-3* Current Limit Ctrl.
Current Lim Cont, Proportional
14-30 Gain
Current Lim Contr, Integration
14-31 Time
14-4* Energy Optimising
14-40 VT Level
14-41 AEO Minimum Magnetisation
14-42 Minimum AEO Frequency
14-43 Motor Cosphi
14-5* Environment
14-50 RFI Filter
14-52 Fan Control
14-53 Fan Monitor
14-55 Output Filter
14-56 Capacitance Output Filter
14-57 Inductance Output Filter
60
How to Programme
Default value (SR - 4-set-up
Size Related)
[1] SFAVM All set-ups
All set-ups
[1] On All set-ups
[0] Off All set-ups
[0] No function All set-ups
SR All set-ups
[0] Trip All set-ups
[0] Manual reset All set-ups
10 s All set-ups
[0] Normal operation All set-ups
2 set-ups
60 s All set-ups
SR All set-ups
[0] No action All set-ups
0 All set-ups
100 % All set-ups
0.020 s All set-ups
66 % All set-ups
40 % All set-ups
10 Hz All set-ups
SR All set-ups
[1] On 1 set-up
[0] Auto All set-ups
[1] Warning All set-ups
[0] No Filter 1 set-up
2.0 uF 1 set-up
7.000 mH 1 set-up
MG.33.A8.02 - VLT is a registered Danfoss trademark
FC 302 Change Conver-
only during sion
operation index
TRUE -
TRUE -
FALSE -
TRUE -
FALSE -
TRUE 0
TRUE -
TRUE -
TRUE 0
TRUE -
FALSE -
TRUE 0
TRUE 0
TRUE -
TRUE 0
FALSE 0
FALSE -3
FALSE 0
TRUE 0
TRUE 0
TRUE -2
x FALSE -
TRUE -
TRUE -
FALSE -
FALSE -7
FALSE -6
Type
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint8
Uint8
Uint16
Uint8
Uint16
Uint8
Uint8
Uint8
Int32
Uint16
Uint16
Uint8
Uint8
Uint8
Uint16
Uint8
Uint8
Uint8
Uint8
Uint16
Uint16
