7-** Controllers
Par. Parameter description
No.
#
7-0* Speed PID Ctrl.
7-00 Speed PID Feedback Source
7-02 Speed PID Proportional Gain
7-03 Speed PID Integral Time
7-04 Speed PID Differentiation Time
7-05 Speed PID Diff. Gain Limit
7-06 Speed PID Lowpass Filter Time
7-08 Speed PID Feed Forward Factor
7-2* Process Ctrl. Feedb
7-20 Process CL Feedback 1 Resource
7-22 Process CL Feedback 2 Resource
7-3* Process PID Ctrl.
Process PID Normal/
7-30 Control
7-31 Process PID Anti Windup
7-32 Process PID Start Speed
7-33 Process PID Proportional Gain
7-34 Process PID Integral Time
7-35 Process PID Differentiation Time
7-36 Process PID Diff. Gain Limit
7-38 Process PID Feed Forward Factor
7-39 On Reference Bandwidth
How to Programme
Default value (SR
- Size Related)
SR
SR
SR
5.0
10.0 ms
0 %
[0] No function
[0] No function
Inverse
[0] Normal
[1] On
0 RPM
0.01
10000.00 s
0.00 s
5.0
0 %
5 %
MG.33.A8.02 - VLT is a registered Danfoss trademark
4-set-up FC 302 Change
only during
operation
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Conver- Type
sion
index
- Uint8
-3 Uint16
-4 Uint32
-4 Uint16
-1 Uint16
-4 Uint16
0 Uint16
- Uint8
- Uint8
- Uint8
- Uint8
67 Uint16
-2 Uint16
-2 Uint32
-2 Uint16
-1 Uint16
0 Uint16
0 Uint8
