2.1.3. IP55 Enclosed Units

2.2. Identifying the Drive by Model Number

Each drive can be identified by its model number, shown below. The model number is on the shipping label and the drive nameplate. The
model number includes the drive and factory fitted options.
Product Range
ODV : Eco Series
Generation
Frame Size
Voltage Code
2 : 200 – 240
4 : 380 – 480
5 : 480 – 525
6 : 500 – 600
Output Current
Shown with 1 decimal place
Supply Phase
1 : 1 Phase Input
3 : 3 Phase Input
6
Optidrive Eco User Guide Revision 2.01
200 – 240 Volt, 3 Phase Input
Frame kW HP
4 7.5 10
4 11 15
5 15 20
5 19 25
6 22 30
6 30 40
6 37 50
6 45 60
7 55 75
7 75 100
380 – 480 Volt, 3 Phase Input
Frame kW HP
4 15 20
4 19 25
4 22 30
5 30 40
5 37 50
5 45 60
6 55 75
6 75 100
6 90 150
7 110 175
7 132 200
7 160 250
480 – 525 Volt, 3 Phase Input
Frame kW HP
7 132 175
7 150 200
7 185 250
7 200 270
500 – 600 Volt, 3 Phase Input
Frame kW HP
4 15 20
4 19 25
4 22 30
4 30 40
5 37 50
5 45 60
5 55 75
6 75 100
6 90 125
6 110 150
ODV - 3 - 4 4
A Model Code
30 ODV-3-420300-3F1N-TN
46 ODV-3-420460-3F1N-TN
61 ODV-3-520610-3F1N-TN
72 ODV-3-520720-3F1N-TN
90 ODV-3-620900-3F1N-TN
110 ODV-3-621100-3F1N-TN
150 ODV-3-621500-3F1N-TN
180 ODV-3-621800-3F1N-TN
202 ODV-3-722020-3F1N-TN
248 ODV-3-722480-3F1N-TN
A Model Code
30 ODV-3-440300-3F1N-TN
39 ODV-3-440390-3F1N-TN
46 ODV-3-440460-3F1N-TN
61 ODV-3-540610-3F1N-TN
72 ODV-3-540720-3F1N-TN
90 ODV-3-540900-3F1N-TN
110 ODV-3-641100-3F1N-TN
150 ODV-3-641500-3F1N-TN
180 ODV-3-641800-3F1N-TN
202 ODV-3-742020-3F1N-TN
240 ODV-3-742400-3F1N-TN
302 ODV-3-743020-3F1N-TN
A Model Code
185 ODV-3-751850-301N-TN
205 ODV-3-752050-301N-TN
255 ODV-3-752550-301N-TN
275 ODV-3-752750-301N-TN
A Model Code
22 ODV-3-460220-301N-TN
28 ODV-3-460280-301N-TN
34 ODV-3-460340-301N-TN
43 ODV-3-460430-301N-TN
54 ODV-3-560540-301N-TN
65 ODV-3-560650-301N-TN
78 ODV-3-560780-301N-TN
105 ODV-3-661050-301N-TN
130 ODV-3-661300-301N-TN
150 ODV-3-661500-301N-TN
0460 - 3 F 1 N - T N
PCB Coating
N : Standard PCB Coating
Display
S : LED IP20 Only
T : OLED IP55 & IP66
Enclosure
2 : IP20
N : IP55
X : IP66 Non Switched
D : IP66 With Disconnect
Brake Transistor
1 : No Brake Transistor
EMC Filter
0 : No EMC Filter
F : With EMC Filter
