2. General Information and Ratings

This chapter contains information about the Optidrive E2 including how to identify the drive
2.1.

Identifying the Drive by Model Number

Each drive can be identified by its model number, as shown in the table below. The model number is on the shipping label and the drive
nameplate. The model number includes the drive and any options.
ODE
Product Family
Generation
Frame Size (1 or 2)
Input Voltage : 1 = 110 – 115V
2 = 200 – 240V
Power Rating
2.2.

Drive Model Numbers

IP20 Drives
110-115V ±10% - 1 Phase Input
kW Model Number
With Filter Without Filter
200-240V ±10% - 1 Phase Input
kW Model Number
With Filter Without Filter
ODE-2-12037-1KB12-01 ODE-2-12037-1K012-01
ODE-2-12075-1KB12-01 ODE-2-12075-1K012-01
ODE-2-22110-1KB42-01 ODE-2-22110-1K042-01
IP66 (Nema 4X) Drives
110-115V ±10% - 1 Phase Input
kW Model Number
With Filter Without Filter
200-240V ±10% - 1 Phase Input
kW Model Number
With Filter Without Filter
ODE-2-12037-1KB1#-01 ODE-2-12037-1K01#-01
ODE-2-12075-1KB1#-01 ODE-2-12075-1K01#-01
ODE-2-22110-1KB4#-01 ODE-2-22110-1K04#-01
NOTE
For IP66 with switches (SWITCHED)change the # for a "Y" at the end of the product code
For IP66 without switches (NON-SWITCHED) change the # for a "X" at the end of the product code
7
Optidrive E2 Single Phase Output User Guide V3.10
- 2 - 1 2 037
kW
ODE-2-11005-1HB12-01
ODE-2-21007-1HB42-01
kW
0.37 ODE-2-12005-1HB12-01
0.75 ODE-2-12010-1HB12-01
1.1 ODE-2-22015-1HB42-01
kW
ODE-2-11005-1HB1#-01
ODE-2-21007-1HB4#-01
kW
0.37 ODE-2-12005-1HB1#-01
0.75 ODE-2-12010-1HB1#-01
1.1 ODE-2-22015-1HB4#-01
www.invertekdrives.com
- 1 K B 1 2
Filter Type
Power Type
No. Of Input Phases
HP Model Number
With Filter Without Filter
ODE-2-11005-1H012-01
ODE-2-21007-1H042-01
HP Model Number
With Filter Without Filter
ODE-2-12005-1H012-01
ODE-2-12010-1H012-01
ODE-2-22015-1H042-01
HP Model Number
With Filter Without Filter
ODE-2-11005-1H01#-01
ODE-2-21007-1H04#-01
HP Model Number
With Filter Without Filter
ODE-2-12005-1H01#-01
ODE-2-12010-1H01#-01
ODE-2-22015-1H04#-01
- 01
Single Phase Output
IP Rating: 2 = IP20
X = IP66 Non Switched
Y = IP66 Switched
Dynamic Brake 1 = No Brake
Transistor: 4 = Brake
0 = No Filter
B = Internal 230V EMC Filter
K = kW
H = HP
HP Output Current (A)
0.5 7
0.75 10.5
HP Output Current (A)
0.5 4.3
1 7
1.5 10.5
HP Output Current (A)
0.5 7
0.75 10.5
HP Output Current (A)
0.5 4.3
1 7
1.5 10.5
Frame
Size
1
2
Frame
Size
1
1
2
Frame
Size
1
2
Frame
Size
1
1
2
