Declaration of Conformity:
Invertek Drives Ltd hereby states that the Optidrive Eco product range conforms to the relevant safety provisions of the Low Voltage
Directive 2006/95/EC and the EMC Directive 2004/108/EC and has been designed and manufactured in accordance with the following
harmonised European standards:
EN 61800-5-1: 2003
nd
EN 61800-3 2 Ed: 2004
EN61000-5-12
EN 55011: 2007
EN60529 : 1992
Electromagnetic Compatibility
All Optidrives are designed with high standards of EMC in mind. All versions intended for use within the European Union are fitted with an
internal EMC filter. This EMC filter is designed to reduce the conducted emissions back into the supply via the power cables for compliance
with harmonised European standards.
It is the responsibility of the installer to ensure that the equipment or system into which the product is incorporated complies with the EMC
legislation of the country of use. Within the European Union, equipment into which this product is incorporated must comply with the EMC
Directive 2004/108/EC. When using an Optidrive with an internal or optional external filter, compliance with the following EMC Categories,
as defined by EN61800-3:2004 can be achieved:
Drive Type / Rating
All Models Use Additional External Filter
ODV-3-x4xxx-3xF1x-Tx
Use screened motor cable
For motor cable lengths greater than 100m, an output dv / dt filter must be used, please refer to the Invertek Stock Drives
Note
Catalogue for further details
All rights reserved. No part of this User Guide may be reproduced or transmitted in any form or by any means, electrical or mechanical
including photocopying, recording or by any information storage or retrieval system without permission in writing from the publisher.
Copyright Invertek Drives Ltd © 2015
All Invertek Optidrive Eco units carry a 2 year warranty against manufacturing defects from the date of manufacture. The manufacturer
accepts no liability for any damage caused during or resulting from transport, receipt of delivery, installation or commissioning. The
manufacturer also accepts no liability for damage or consequences resulting from inappropriate, negligent or incorrect installation, incorrect
adjustment of the operating parameters of the drive, incorrect matching of the drive to the motor, incorrect installation, unacceptable dust,
moisture, corrosive substances, excessive vibration or ambient temperatures outside of the design specification.
The local distributor may offer different terms and conditions at their discretion, and in all cases concerning warranty, the local distributor
should be contacted first.
Thisuserguideisthe"originalinstructions"document.llnon-Englishversionsaretranslationsofthe"originalinstructions".
Contents of this User Guide are believed to be correct at the time of printing. In the interest of a commitment to a policy of continuous
improvement, the manufacturer reserves the right to change the specification of the product or its performance or the contents of the User
Guide without notice.
The contents of this User Guide are believed to be correct at the time of printing. In the interest of a commitment to a policy of continuous
improvement, the manufacturer reserves the right to change the specification of the product or its performance or the contents of the User
Guide without notice.
This User Guide is for use with version 2.01 Firmware. The firmware version can be viewed in parameter P0-28.
User Guide Revision 2.01
Invertek Drives Ltd adopts a policy of continuous improvement and whilst every effort has been made to provide accurate and up to date
information, the information contained in this User Guide should be used for guidance purposes only and does not form the part of any
contract.
2
Optidrive Eco User Guide Revision 2.01
Adjustable speed electrical power drive systems. Safety requirements. Electrical, thermal and energy.
Adjustable speed electrical power drive systems. EMC requirements and specific test methods
Limits for harmonic currents produced by equipment connected to public low-voltage systems with
input current > 16 A and <= 75 A per phase. Requirements are fulfilled without the need for Line
Reactors according to the THC values specified in Table 3 for values of R
for operation on 400 Volt, 3 Phase Supply.
Limits and Methods of measurement of radio disturbance characteristics of industrial, scientific and
medical (ISM) radio-frequency equipment (EMC)
Specifications for degrees of protection provided by enclosures
Cat C1
No additional filtering required
EMC Category
Cat C2
> 185 for all units intended
SCE
Cat C3
