Par Parameter Name
P5-09 BACnet Device Instance Number (Low)
P5-10 BACnet Device Instance Number (High)
When using BACNet MS/TP, these parameter together allow a unique Device Instance Number to be programmed into the drive.
For further information on using BACnet MS/TP, refer to section 11.3
P5-11 BACnet Maximum Masters
Parameter defines the maximum address of any BACnet masters that can exist on the current local MSTP BACnet network. Refer
to section 11.3 for further information.
When the device is polling for the next master in the network it will not poll about the value set in P5-11. For example, if the value
is set to 50 then when the drive finishes communicating and needs to pass control to the next master it will poll up to address 50
looking for a response before rolling back to address 0.
P5-12 Fieldbus Module PDO3
When using an optional Fieldbus interface, this parameter configures the parameter source for the 3rd process data word
transferred from the drive to the network master during cyclic communications:
0 : Motor Current – With one decimal place, e.g. 100
1 : Output Power – Output power in kW to two decimal places, e.g. 400 = 4.00kW
2 : Digital Input Status – Bit 0 indicates digital input 1 status, bit 1 indicates digital input 2 status etc.
3 : Analog Input 2 Signal Level – 0 to 1000 = 0 to 100.0%
4 : Drive Heat-sink Temperature – 0 to 100 = 0 to 100°C
5 : User Register 1 – Can be accessed by PLC program or group 9 parameters
4 : User Register 2 – Can be accessed by PLC program or group 9 parameters
7 : P0-80 Value - P0-80 value can be selected by P6-28
P5-13 Fieldbus Module PDI4
When using an optional Fieldbus interface, this parameter configures the parameter source for the 4th process data word
transferred from the network master to the drive during cyclic communications:
0: User ramp time – In second with two decimal places.
1: User Register 4 – Can be accessed by PLC program or group 9 parameters
P5-14 Fieldbus Module PDI3
When using an optional Fieldbus interface, this parameter configures the parameter source for the 3rd process data word
transferred from the network master to the drive during cyclic communications:
0 : Not used - No function
1 : User PID Reference - 0 to 1000 = 0% to 100.0%
2 : User Register 3 – Can be accessed by PLC program or group 9 parameters
P5-15 Modbus Response Delay
Allows the user to configure an additional delay between the drive receiving a request via the Modbus RTU interface, and
transmitting a reply. The value entered represents the delay in addition to the minimum delay permissible according to the
Modbus RTU specification, and is expressed as the number of additional characters.
10.5. Parameter Group 8 – Application Function Specific Parameters
Par Parameter Name
P8-01 Pump Stir Interval Duration
This parameter can be used to set a pre-defined period of inactivity, whereby if the drive remains in standby mode for a period of
time exceeding the limit, stir function is activated, and the drive will operate at preset speed 7 (P2-07) for the time set in P8-02.
This allows the pump to stir, preventing sediment from settling and avoiding a blockage.
P8-02 Pump Stir Activation Time
Set the time period that the stir function will be active once triggered (excludes time for deceleration to stop)
P8-03 Pump Clean Function Select
This parameter configures the drive conditions that will cause activation of the automatic pump clean function. When activated,
the pump clean will operate the pump at preset speed 5 (P2-05) for the time period set in P8-04, followed by Preset Speed 6 (P2-
06) (Providing P2-06 <> 0) for the time set in P8-04, before resuming normal operation. During the cleaning cycle, the ramp time
set in P8-05 is used for both acceleration and deceleration, and overrides P1-03 and P1-04.
Where possible, P2-05 and P2-06 may be set to negative values, to allow the pump to be reversed. For best results, it is
recommended to use as high a speed as possible, and to adjust P8-05 to allow a short acceleration time whilst avoiding over
current trips.
0 : Disabled
1 : Active on start-up only. The pump cleaning function operates every time the pump is started.
2 : Active on start-up and over-torque detection. The pump cleaning function operates every time the pump is started, and also
in the event that the drive detects a possible pump blockage during normal operation. This requires the Load Profile Monitoring
function to be active and commissioned for correct operation, see parameter P8-06.
3 : Active on over-torque detection only. The pump cleaning function operates only when a possible pump blockage is detected
during normal operation. This requires the Load Profile Monitoring function to be active and commissioned for correct operation,
see parameter P8-06.
Note: The pump clean function can also be activated by digital input configured in group 9 parameters.
P8-04 Cleaning Time
Sets the time period for the operation of the pump cleaning cycle. When bi-directional pump cleaning is selected, the time
interval is used twice, once in each direction.
P8-05 Clean Function Ramp Time
Independent ramp rate used only for the pump automatic cleaning function (see P8-03) when the motor is Accelerated as part of
the cleaning cycle.
www.microlectra.nl
Optidrive Eco User Guide Revision 2.01
Minimum Maximum Default
0 65535
0 63
0 127
0 7
0 1
0 2
0 16
Minimum Maximum Default
0 60000
1 6000
0 3
0 600
0.0 6000
Units
1 -
0 -
127 -
0 -
0 -
0 -
0 Chr
Units
0 mins
10 Secs
0 -
0 Secs
30 Secs
